Sony CFD-CD777S - Specifications

Additional Information30
Specifications
CD player section
System
Compact disc digital audio system
Laser diode properties
Material: GaAlAs
Wave length: 780 nm
Emission duration: Continuous
Laser output: Less than 44.6 µW
(This output is the value measured at a distance of
about 200 mm from the objective lens surface on
the optical pick-up block with 7 mm aperture.)
Spindle speed
200 r/min (rpm) to 500 r/min (rpm) (CLV)
Number of channels
2
Frequency response
20 - 20,000 Hz +0/–1.5 dB
Wow and flutter
Below measurable limit
Radio section
Frequency range
CFD-CD777S
FM Saudi arabia 87.6 - 107 MHz
Other countries 87.6 - 108 MHz
MW 530 - 1,605 kHz
SW1 2.3 - 7 MHz
SW2 7 - 22 MHz
CFD-CD777L
FM 65.0 - 108 MHz
MW 531 - 1,602 kHz
LW 153 - 279 kHz
SW 5.95 - 18 MHz
IF
FM: 10.7 MHz
SW/MW/LW: 455 kHz
Antennas
FM/SW: Telescopic antenna
MW/LW: Built-in ferrite bar antenna
Cassette-corder section
Recording system
4-track 2 channel stereo
Fast winding time
Approx. 120 s (sec.) with Sony cassette C-60
Frequency response
TYPE I (normal): 80 - 12,500 Hz
General
Speaker
Woofer: 10 cm (4 in.) dia., 4 ohms, cone type (2)
Tweeter: 5 cm (2 in.) dia.,
Outputs
Headphones jack (stereo minijack)
For 16 - 68 ohms impedance headphones
Maximum power output
12 W + 12 W
Power requirements
For CD radio cassette-corder:
CFD-CD777S
110 - 120, 220 - 240 V AC selectable, 50/60 Hz
CFD-CD777L
230 V AC, 50 Hz
12 V DC, 8 R20 (size D) batteries
For remote control:
3 V DC, 2 R6 (size AA) batteries
Power consumption
AC 47 W
Battery life
For CD radio cassette-corder:
FM recording
Sony R20P: approx. 4 h
Sony alkaline LR20: approx. 9 h
Tape playback
Sony R20P: approx. 2 h
Sony alkaline LR20: approx. 4 h
CD playback
Sony R20P: approx. 1.5 h
Sony alkaline LR20: approx. 3 h
