– 65 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
* A-3323-290-A MAIN BOARD, COMPLETE
*********************
3-040-820-01 PLATE (TUN), SHIELD
< CAPACITOR >
C2 1-162-306-11 CERAMIC 0.01uF 20% 16V
C3 1-162-306-11 CERAMIC 0.01uF 20% 16V
C4 1-162-306-11 CERAMIC 0.01uF 20% 16V
C5 1-162-306-11 CERAMIC 0.01uF 20% 16V
C6 1-102-961-00 CERAMIC 27PF 5% 50V
C7 1-162-306-11 CERAMIC 0.01uF 20% 16V
C8 1-162-306-11 CERAMIC 0.01uF 20% 16V
C9 1-162-306-11 CERAMIC 0.01uF 20% 16V
C10 1-127-888-21 CERAMIC 0.1uF 10% 50V
C11 1-128-808-21 CERAMIC 82PF 5% 50V
C12 1-162-306-11 CERAMIC 0.01uF 20% 16V
C13 1-162-306-11 CERAMIC 0.01uF 20% 16V
C14 1-128-816-51 CERAMIC 390PF 5% 50V
C15 1-162-306-11 CERAMIC 0.01uF 20% 16V
C16 1-128-815-11 CERAMIC 330PF 5% 50V
C17 1-162-201-31 CERAMIC 12PF 5% 50V
C18 1-162-306-11 CERAMIC 0.01uF 20% 16V
C19 1-162-306-11 CERAMIC 0.01uF 20% 16V
C41 1-126-934-11 ELECT 220uF 20% 10V
C45 1-126-960-11 ELECT 1uF 20% 50V
C46 1-162-301-11 CERAMIC 0.0015uF 20% 16V
C47 1-162-306-11 CERAMIC 0.01uF 20% 16V
C48 1-126-963-11 ELECT 4.7uF 20% 50V
C49 1-127-878-21 CERAMIC 0.015uF 10% 50V
C50 1-127-878-21 CERAMIC 0.015uF 10% 50V
C51 1-126-960-11 ELECT 1uF 20% 50V
C52 1-126-960-11 ELECT 1uF 20% 50V
C53 1-126-960-11 ELECT 1uF 20% 50V
C54 1-162-288-31 CERAMIC 330PF 10% 50V
C55 1-162-306-11 CERAMIC 0.01uF 20% 16V
C56 1-126-959-11 ELECT 0.47uF 20% 50V
C57 1-127-888-21 CERAMIC 0.1uF 10% 50V
C58 1-162-306-11 CERAMIC 0.01uF 20% 16V
C59 1-127-888-21 CERAMIC 0.1uF 10% 50V
C61 1-162-198-31 CERAMIC 8.2PF 10% 50V
C62 1-162-199-31 CERAMIC 10PF 5% 50V
C63 1-136-171-00 MYLAR 0.33uF 5% 50V
C64 1-126-925-11 ELECT 470uF 20% 10V
C65 1-127-888-21 CERAMIC 0.1uF 10% 50V
C66 1-162-306-11 CERAMIC 0.01uF 20% 16V
C67 1-162-294-31 CERAMIC 0.001uF 10% 50V
C68 1-162-306-11 CERAMIC 0.01uF 20% 16V
C69 1-161-494-00 CERAMIC 0.022uF 25V
C70 1-162-282-31 CERAMIC 100PF 10% 50V
C71 1-162-282-31 CERAMIC 100PF 10% 50V
C72 1-162-282-31 CERAMIC 100PF 10% 50V
C73 1-162-294-31 CERAMIC 0.001uF 10% 50V
C74 1-162-306-11 CERAMIC 0.01uF 20% 16V
C81 1-162-306-11 CERAMIC 0.01uF 20% 16V
C82 1-162-306-11 CERAMIC 0.01uF 20% 16V
C83 1-162-294-31 CERAMIC 0.001uF 10% 50V
C84 1-127-888-21 CERAMIC 0.1uF 10% 50V
C88 1-162-306-11 CERAMIC 0.01uF 20% 16V
C101 1-127-866-21 CERAMIC 1500PF 10% 50V
C102 1-104-664-11 ELECT 47uF 20% 10V
C103 1-127-883-21 CERAMIC 0.039uF 10% 50V
C104 1-162-302-11 CERAMIC 0.0022uF 20% 16V
C105 1-162-282-31 CERAMIC 100PF 10% 50V
C106 1-126-964-11 ELECT 10uF 20% 50V
C121 1-162-301-11 CERAMIC 0.0015uF 20% 16V
C122 1-126-964-11 ELECT 10uF 20% 50V
C123 1-127-884-21 CERAMIC 0.047uF 10% 50V
C124 1-127-884-21 CERAMIC 0.047uF 10% 50V
C125 1-127-876-21 CERAMIC 0.01uF 10% 50V
C126 1-126-964-11 ELECT 10uF 20% 50V
C201 1-127-866-21 CERAMIC 1500PF 10% 50V
C202 1-104-664-11 ELECT 47uF 20% 10V
C203 1-127-883-21 CERAMIC 0.039uF 10% 50V
C204 1-162-302-11 CERAMIC 0.0022uF 20% 16V
C205 1-162-282-31 CERAMIC 100PF 10% 50V
C206 1-126-964-11 ELECT 10uF 20% 50V
C221 1-162-301-11 CERAMIC 0.0015uF 20% 16V
C222 1-126-964-11 ELECT 10uF 20% 50V
C223 1-127-884-21 CERAMIC 0.047uF 10% 50V
C224 1-127-884-21 CERAMIC 0.047uF 10% 50V
C225 1-127-876-21 CERAMIC 0.01uF 10% 50V
C226 1-126-964-11 ELECT 10uF 20% 50V
C301 1-104-665-11 ELECT 100uF 20% 10V
C302 1-104-665-11 ELECT 100uF 20% 10V
C303 1-104-665-11 ELECT 100uF 20% 10V
C304 1-162-294-31 CERAMIC 0.001uF 10% 50V
C305 1-162-306-11 CERAMIC 0.01uF 20% 16V
C306 1-126-964-11 ELECT 10uF 20% 50V
C317 1-162-282-31 CERAMIC 100PF 10% 50V
C318 1-162-282-31 CERAMIC 100PF 10% 50V
C321 1-126-961-11 ELECT 2.2uF 20% 50V
C322 1-104-664-11 ELECT 47uF 20% 10V
C323 1-104-665-11 ELECT 100uF 20% 10V
C324 1-126-934-11 ELECT 220uF 20% 10V
C325 1-126-964-11 ELECT 10uF 20% 50V
C327 1-127-880-21 CERAMIC 0.022uF 10% 50V
C328 1-127-880-21 CERAMIC 0.022uF 10% 50V
C330 1-162-282-31 CERAMIC 100PF 10% 50V
C331 1-162-282-31 CERAMIC 100PF 10% 50V
C332 1-162-600-11 CERAMIC 0.0047uF 20% 16V
C333 1-126-960-11 ELECT 1uF 20% 50V
C334 1-126-964-11 ELECT 10uF 20% 50V
C335 1-126-964-11 ELECT 10uF 20% 50V
C336 1-127-888-21 CERAMIC 0.1uF 10% 50V
C337 1-162-306-11 CERAMIC 0.01uF 20% 16V
C361 1-127-880-21 CERAMIC 0.022uF 10% 50V
C362 1-126-934-11 ELECT 220uF 20% 16V
C363 1-127-878-21 CERAMIC 0.015uF 10% 50V
C364 1-162-306-11 CERAMIC 0.01uF 20% 16V
C365 1-126-963-11 ELECT 4.7uF 20% 50V
< FILTER >
CF1 1-579-083-11 FILTER, CERAMIC
CF3 1-781-171-11 DISCRIMINATOR, CERAMIC
CF4 1-781-344-11 FILTER, AM CERAMIC
