8
CFD-E90L
3-3. POWER BOARD
3-4. TUNER BOARD
5
screw
(2.6
×
8)
4
3
screw (2.6
×
10)
2
three screws
(2.6
×
8)
1
connector
(CNP1)
7
TUNER board
6
tuner PC board holder
1
connector
(CNP901)
3
2
two screws
(2.6
×
10)
4
connector
(CNP322)
5
POWER board
