59
CFD-G700CP/G770CP/G770CPK
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< SWITCH >
S401 1-786-050-21 SWITCH, KEY BOARD (TUNE –/ –)
S402 1-786-050-21 SWITCH, KEY BOARD (TUNE +/ +)
S405 1-786-050-21 SWITCH, KEY BOARD (u)
S406 1-786-050-21 SWITCH, KEY BOARD (x)
S413 1-786-050-21 SWITCH, KEY BOARD (PRESET – .)
S414 1-786-050-21 SWITCH, KEY BOARD (PRESET + >)
*************************************************************
A-1244-302-A D-LIGHT BOARD, COMPLETE (G700CP)
***********************
< JACK >
J103 1-820-048-11 CONNECTOR (LIGHTING) (D-LIGHT SYNC OUT)
< RESISTOR >
L302 1-216-864-11 SHORT CHIP 0
L306 1-216-864-11 SHORT CHIP 0
L307 1-216-864-11 SHORT CHIP 0
*************************************************************
A-1244-297-A HEADPHONE BOARD, COMPLETE
***************************
< CONNECTOR >
CNP392 1-815-552-11 PIN, CONNECTOR (PWB) 4P
< JACK >
J391 1-794-016-11 JACK (i)
< COIL >
L301 1-410-509-11 INDUCTOR 10uH
< RESISTOR >
R192 1-216-821-11 METAL CHIP 1K 5% 1/10W
R193 1-216-813-11 METAL CHIP 220 5% 1/10W
R194 1-216-813-11 METAL CHIP 220 5% 1/10W
R292 1-216-821-11 METAL CHIP 1K 5% 1/10W
R293 1-216-813-11 METAL CHIP 220 5% 1/10W
R294 1-216-813-11 METAL CHIP 220 5% 1/10W
*************************************************************
A-1244-292-A LCD BOARD, COMPLETE
********************
1-831-799-21 CABLE, FLEXIBLE FLAT (19 CORE)
2-895-582-01 HOLDER, LCD
3-198-120-01 SHEET (IR), ADHESIVE
< CAPACITOR >
C401 1-115-156-11 CERAMIC CHIP 1uF 10V
< DIODE >
D406 8-719-059-97 DIODE L-34HD (OPR/BATT)
< IC >
IC891 6-701-681-01 IC RPM7140-V4
< LIQUID CRYSTAL DISPLAY >
LCD401 1-802-396-11 DISPLAY PANEL, LIQUID CRYSTAL
< RESISTOR >
R428 1-216-813-11 METAL CHIP 220 5% 1/10W
R469 1-216-845-11 METAL CHIP 100K 5% 1/10W
R475 1-216-849-11 METAL CHIP 220K 5% 1/10W
*************************************************************
A-1243-618-A LED1 BOARD, COMPLETE
********************
< RESISTOR >
R471 1-216-813-11 METAL CHIP 220 5% 1/10W
R472 1-216-813-11 METAL CHIP 220 5% 1/10W
*************************************************************
A-1243-619-A LED2 BOARD, COMPLETE
********************
< RESISTOR >
R449 1-216-813-11 METAL CHIP 220 5% 1/10W
R450 1-216-813-11 METAL CHIP 220 5% 1/10W
*************************************************************
A-1243-620-A LED3 BOARD, COMPLETE
********************
< RESISTOR >
R476 1-216-813-11 METAL CHIP 220 5% 1/10W
R487 1-216-813-11 METAL CHIP 220 5% 1/10W
*************************************************************
A-1243-621-A LED4 BOARD, COMPLETE
********************
< RESISTOR >
R478 1-216-813-11 METAL CHIP 220 5% 1/10W
R479 1-216-813-11 METAL CHIP 220 5% 1/10W
*************************************************************
A-1244-300-A MAIN BOARD, COMPLETE (MX, E92)
A-1244-370-A MAIN BOARD, COMPLETE (G700CP)
A-1244-371-A MAIN BOARD, COMPLETE (CND)
A-1244-372-A MAIN BOARD, COMPLETE (SP)
A-1244-373-A MAIN BOARD, COMPLETE (E41)
A-1244-374-A MAIN BOARD, COMPLETE (AUS)
*********************
1-832-425-21 CABLE, FLEXIBLE FLAT (11 CORE)
1-833-945-21 CABLE, FLEXIBLE FLAT (11 CORE)
3-252-827-01 SCREW (B2.6), (+) BV TAPPING
< CAPACITOR >
C106 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C107 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C108 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C109 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C110 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C111 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C121 1-126-960-11 ELECT 1uF 20% 50V
LED1
LCDCD KEY D-LIGHT HEADPHONE
LED2 LED3 LED4 MAIN
