NOTE :
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms
METAL : Metal-film resistor
METAL OXIDE :Metal oxide-film resistor
F : nonflammable
• Items marked “ * ”are not stocked since
they are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u : µ , for example :
uA.... : µ A.... , uPA.... : µ PA....
uPB.... : µ PB.... , uPC.... : µ PC....
uPD.... : µ PD....
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• Abbreviation
IT : Italian
AUS : Australian
EE : East European
When indicating parts by reference num-
ber, please include the board.
The components identified by mark !
or dotted line with mark ! are critical
for safety.
Replace only with part number specified.
SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* 1-666-267-11 AC INLET BOARD
**************
< CAPACITOR >
C907 1-162-294-31 CERAMIC 0.001uF 10% 50V
< DIODE >
D905 8-719-055-76 DIODE 1N4148
D906 8-719-055-76 DIODE 1N4148
< JACK >
!J901 1-526-838-11 INLET, AC 2P (⁄ AC IN)
************************************************************
* 1-666-266-11 BATT BOARD
***********
************************************************************
1-639-678-12 CD MOTOR BOARD
****************
< CONNECTOR >
CNP707 1-564-722-11 PIN, CONNECTOR (SMALL TYPE) 6P
< SWITCH >
S701 1-572-085-11 SWITCH, LEAF (LIMIT)
************************************************************
* A-3306-681-A MAIN BOARD, COMPLETE (AUS)
* A-3321-122-A MAIN BOARD, COMPLETE (EXCEPT AUS)
*********************
* 3-009-219-01 HOLDER, LCD
7-621-770-99 SCREW +P 2.6X8
7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
< CAPACITOR >
C101 1-162-301-11 CERAMIC 0.0015uF 20% 16V
C103 1-104-664-11 ELECT 47uF 20% 10V
C104 1-161-020-11 CERAMIC 0.039uF 10% 25V
C105 1-162-302-11 CERAMIC 0.0022uF 20% 16V
C111 1-124-902-00 ELECT 0.47uF 20% 50V
C113 1-124-903-11 ELECT 1uF 20% 50V
C121 1-124-902-00 ELECT 0.47uF 20% 50V
C122 1-104-664-11 ELECT 47uF 20% 10V
C191 1-126-927-11 ELECT 2200uF 20% 10V
C192 1-124-903-11 ELECT 1uF 20% 50V
C194 1-126-961-11 ELECT 2.2uF 20% 50V
C195 1-136-153-00 FILM 0.01uF 5% 50V
C201 1-162-301-11 CERAMIC 0.0015uF 20% 16V
C203 1-104-664-11 ELECT 47uF 20% 10V
C204 1-161-020-11 CERAMIC 0.039uF 10% 25V
C205 1-162-302-11 CERAMIC 0.0022uF 20% 16V
C211 1-124-902-00 ELECT 0.47uF 20% 50V
C213 1-124-903-11 ELECT 1uF 20% 50V
C221 1-124-902-00 ELECT 0.47uF 20% 50V
C222 1-104-664-11 ELECT 47uF 20% 10V
C291 1-126-927-11 ELECT 2200uF 20% 10V
C292 1-124-903-11 ELECT 1uF 20% 50V
C295 1-136-153-00 FILM 0.01uF 5% 50V
C301 1-126-937-11 ELECT 4700uF 20% 16V
C302 1-104-666-11 ELECT 220uF 20% 16V
C303 1-162-306-11 CERAMIC 0.01uF 30% 16V
(NEW TYPE)
C304 1-124-443-00 ELECT 100uF 20% 10V
C305 1-124-443-00 ELECT 100uF 20% 10V
C306 1-124-443-00 ELECT 100uF 20% 10V
C308 1-126-233-11 ELECT 22uF 20% 50V
C312 1-136-165-00 FILM 0.1uF 5% 50V
C313 1-136-157-00 FILM 0.022uF 5% 50V
C314 1-136-153-00 FILM 0.01uF 5% 50V
C315 1-124-472-11 ELECT 470uF 20% 10V
C316 1-136-153-00 FILM 0.01uF 5% 50V
C322 1-136-165-00 FILM 0.1uF 5% 50V
C323 1-136-157-00 FILM 0.022uF 5% 50V
C324 1-136-153-00 FILM 0.01uF 5% 50V
C325 1-124-903-11 ELECT 1uF 20% 50V
C327 1-136-165-00 FILM 0.1uF 5% 50V
C328 1-126-963-11 ELECT 4.7uF 20% 50V
C329 1-162-302-11 CERAMIC 0.0022uF 30% 16V
C330 1-162-302-11 CERAMIC 0.0022uF 30% 16V
C331 1-162-294-31 CERAMIC 0.001uF 10% 50V
C332 1-124-903-11 ELECT 1uF 20% 50V
C333 1-124-443-00 ELECT 100uF 20% 10V
AC INLET
CD MOTOR MAIN
BATT
