2
1
Place the console with the rear side facing up, and
then remove the cap from the screw hole.
2
Store the cap in the bottom of the base, and then
remove the screw from the bottom of the base.
3
Attach the base, and then secure with the screw using
your hand. You can also use a coin to tighten the
screw.
Bottom of
base
Let’s get started
1
Attach the base.
Always attach the base to the console, whether it’s in the
vertical or horizontal position.
Place your console on a flat surface when attaching the
base.
You’ll need to reconfigure the base for the position
of your console. Rotate the top and bottom part of
the base in opposite directions. Keep rotating until
you hear a “click”.
For the vertical position
Hook
With the base attached
Make sure the hook is in the position
as illustrated below before attaching
the base to the console.
To Next Page
