– 6 –
2-5. MECHANISM DECK, DECK CONTROL BOARD, VOLUME BOARD REMOVAL
1
6
9
4
2
DECK CONTROL board
Volume board
8
Screws (+BV 3x10)
5
Screws (+BV 3x10
)
3
Screw +BV (3x10)
3
Screws (+BV 3x10)
7
Knob (TONE SW)
7
Knob (VOL)
Cabinet (Front) assy
Mechanism deck
