– 5 –
2-3. MAIN BOARD, TUN LED BOARD, TACT SW BOARD REMOVAL
5
2
4
4
3
7
6
1 Screws (+BV 3x10)
Cabinet (Front) assy
Main board
Chassis, TU
TACT SW board
TUN LED board
2-4. H/P JACK BOARD, DOOR EAR (PH), BOX EAR (PH) REMOVAL
5
1
1
2
3
H/P JACK board
4 Screw (+BV 3x10)
4 Screw (+BV 3x10)
6 Screw
(+BV 3x10)
Box, ear(PH)
DOOR, ear(PH)
Cabinet (Front) assy
