CPD-200ES
SECTION 2
DISASSEMBLY
2-3. D BOARD REMOVAL
Cable bracket
Cable stopper
Five screws
(BVTP 3 x 12)
D board
One screw
(BVTT 4 x 8)
1
2
3
5
6
7
A board
Two screws
(BVTP 3 x 12)
4
1
2
3
A board
D board
2-1. CABINET REMOVAL 2-2. SERVICE POSITION
1
2
Four screws
(BVTP 4 x 16)
Cabinet
