Sony D-E200 - Semiconductor and Connector Part Details; Resistor Part Details

– 29 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
C626 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C627 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C628 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C629 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C630 1-162-925-11 CERAMIC CHIP 68PF 5% 50V
C631 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C632 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C633 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C634 1-124-635-11 ELECT 220uF 20% 10V
C635 1-115-156-11 CERAMIC CHIP 1uF 10V
C636 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C639 1-115-156-11 CERAMIC CHIP 1uF 10V
C800 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C801 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C802 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C803 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C804 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C805 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C806 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C807 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C808 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C809 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C810 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C811 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C841 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN501 1-566-530-11 CONNECTOR, FPC (ZIF) 14P
* CN502 1-695-320-21 PIN, CONNECTOR (1.5mm) (SMD) 2P
* CN503 1-695-320-31 PIN, CONNECTOR (1.5mm) (SMD) 2P
< DIODE >
D401 8-719-077-01 DIODE CRS03(TE85L)
D406 8-719-058-24 DIODE RB501V-40TE-17
D408 8-719-049-09 DIODE 1SS367-T3SONY
D409 8-719-976-96 DIODE UDZ-TE-17-4.7B
D410 8-719-077-01 DIODE CRS03(TE85L)
D461 8-719-049-09 DIODE 1SS367-T3SONY
D601 8-719-941-86 DIODE DAN202UT106
< JUMPER RESISTOR >
FB111 1-216-864-11 METAL CHIP 0 5% 1/16W
FB211 1-216-864-11 METAL CHIP 0 5% 1/16W
FB311 1-216-864-11 METAL CHIP 0 5% 1/16W
FB602 1-216-864-11 METAL CHIP 0 5% 1/16W
FB603 1-216-864-11 METAL CHIP 0 5% 1/16W
< IC >
IC302 8-759-522-87 IC TA2120FN(EL)
IC401 8-759-670-16 IC TB2119FA
IC402 8-759-651-13 IC NJU7116F(TE2)
IC403 8-759-577-33 IC RN5RZ20BA-TR
IC601 8-752-398-18 IC CXD3027R
IC602 8-759-594-56 IC MSM51X17400D-10TFSR1 (E251)
IC603 8-759-670-17 IC MSM51V4400D-70SJ7FS1
(E200/E201/E206CK)
IC801 8-759-671-03 IC TMP88CH22F-1A75
< JACK >
J302 1-774-804-11 JACK (PHONES)
J401 1-778-153-21 JACK, DC (POLARITY UNIFIED TYPE)
(DC IN 4.5V)
< COIL >
L401 1-419-544-21 COIL, CHOKE
L402 1-469-525-91 INDUCTOR 10uH
L403 1-412-054-21 INDUCTOR 2.2uH
L404 1-412-054-21 INDUCTOR 2.2uH
L408 1-412-039-51 INDUCTOR CHIP 100uH
L409 1-469-527-91 INDUCTOR 47uH
L410 1-469-527-91 INDUCTOR 47uH
< LIQUID CRYSTAL DISPLAY >
LCD801 1-803-945-11 DISPLAY PANEL, LIQUID CRYSTAL
< TRANSISTOR >
Q401 8-729-921-93 TRANSISTOR 2SB1182F5-QR-TLQR
Q402 8-729-920-82 TRANSISTOR 2SB1188-QR
Q403 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR
Q404 8-729-050-11 TRANSISTOR UMW1NTR
Q405 8-729-905-40 TRANSISTOR 2SC4081T106
Q406 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR
Q408 8-729-029-10 TRANSISTOR DTC143TUA-T106
Q410 8-729-922-10 TRANSISTOR 2SA1577-T106-QR
Q411 8-729-905-40 TRANSISTOR 2SC4081T106
Q501 8-729-930-38 TRANSISTOR UMS2-TR
Q502 8-729-050-11 TRANSISTOR UMW1NTR
Q503 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR
Q504 8-729-930-41 TRANSISTOR UMW2-TR
< RESISTOR >
R1 1-216-864-11 METAL CHIP 0 5% 1/16W
R2 1-216-864-11 METAL CHIP 0 5% 1/16W
R3 1-216-864-11 METAL CHIP 0 5% 1/16W
R4 1-412-002-31 INDUCTOR 4.7uH
R5 1-410-993-42 INDUCTOR 1uH
R101 1-216-835-11 METAL CHIP 15K 5% 1/16W
R102 1-216-864-11 METAL CHIP 0 5% 1/16W
R104 1-216-837-11 METAL CHIP 22K 5% 1/16W
R107 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R154 1-216-793-11 RES-CHIP 4.7 5% 1/16W
R201 1-216-835-11 METAL CHIP 15K 5% 1/16W
R202 1-216-864-11 METAL CHIP 0 5% 1/16W
R204 1-216-837-11 METAL CHIP 22K 5% 1/16W
R207 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R254 1-216-793-11 RES-CHIP 4.7 5% 1/16W
