– 28 –
SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.
A-3323-506-A MAIN BOARD, COMPLETE (E200/E201/E206CK)
A-3323-518-A MAIN BOARD, COMPLETE (E251)
*********************
< BATTERY TERMINAL >
BT401 4-978-695-01 PLATE, TERMINAL, BATTERY
BT402 4-978-695-01 PLATE, TERMINAL, BATTERY
< CAPACITOR >
C102 1-216-864-11 METAL CHIP 0 5% 1/16W
C103 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C104 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C105 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C154 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C202 1-216-864-11 METAL CHIP 0 5% 1/16W
C203 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C204 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C205 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C254 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C300 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C351 1-115-156-11 CERAMIC CHIP 1uF 10V
C352 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C353 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C354 1-128-057-11 ELECT 330uF 20% 6.3V
C401 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C402 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C403 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C404 1-104-913-11 TANTAL. CHIP 10uF 20% 16V
C405 1-115-156-11 CERAMIC CHIP 1uF 10V
C406 1-104-752-11 TANTAL. CHIP 33uF 20% 6.3V
C407 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C408 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C409 1-110-569-11 TANTAL. CHIP 47uF 20% 4V
C410 1-110-569-11 TANTAL. CHIP 47uF 20% 4V
C411 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C412 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C413 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C414 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C415 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C416 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C417 1-110-569-11 TANTAL. CHIP 47uF 20% 4V
C418 1-124-635-00 ELECT 220uF 20% 6.3V
C419 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C421 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C422 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C423 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C424 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C425 1-115-156-11 CERAMIC CHIP 1uF 10V
C427 1-110-569-11 TANTAL. CHIP 47uF 20% 4V
C428 1-164-156-11 CERAMIC CHIP 0.1uF 16V
C429 1-164-156-11 CERAMIC CHIP 0.1uF 16V
C430 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C431 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C442 1-115-156-11 CERAMIC CHIP 1uF 10V
C451 1-164-346-11 CERAMIC CHIP 1uF 16V
C453 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C461 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C462 1-162-925-11 CERAMIC CHIP 68PF 5% 50V
C500 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C501 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C502 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C503 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C504 1-162-907-11 CERAMIC CHIP 2PF 0.25PF 50V
C505 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C506 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C508 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C601 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C602 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C603 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C604 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C605 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C606 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C607 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C608 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C609 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C611 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C612 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C613 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C614 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C615 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C616 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C617 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C618 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C619 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C621 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C622 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C623 1-115-156-11 CERAMIC CHIP 1uF 10V
C624 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C625 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
• Abbreviation
CND : Canadian model
MAIN
