Sony D-E200 - Electrical Parts List; Switch, Varistor, and Vibrator Parts

– 31 –
Ref. No. Part No. Description Remark
MAIN
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
R811 1-218-863-11 METAL CHIP 4.7K 0.5% 1/16W
R812 1-218-855-11 METAL CHIP 2.2K 0.5% 1/16W
R813 1-216-837-11 METAL CHIP 22K 5% 1/16W
(E251)
R813 1-216-839-11 METAL CHIP 33K 5% 1/16W
(E200/E201/E206CK)
R814 1-216-845-11 METAL CHIP 100K 5% 1/16W
R817 1-218-851-11 METAL CHIP 1.5K 0.5% 1/16W
R818 1-216-847-11 METAL CHIP 150K 5% 1/16W
(E200/E201/E206CK)
R818 1-216-851-11 METAL CHIP 330K 5% 1/16W
(E251)
R819 1-216-845-11 METAL CHIP 100K 5% 1/16W
R820 1-218-847-11 METAL CHIP 1K 0.5% 1/16W
R823 1-216-845-11 METAL CHIP 100K 5% 1/16W
R824 1-216-845-11 METAL CHIP 100K 5% 1/16W
R826 1-216-851-11 METAL CHIP 330K 5% 1/16W
R829 1-216-864-11 METAL CHIP 0 5% 1/16W
R841 1-216-857-11 METAL CHIP 1M 5% 1/16W
< SWITCH >
S801 1-762-822-11 SWITCH, PUSH (1 KEY) (OPEN)
S802 1-572-922-11 SWITCH, SLIDE (MEGA BASS)
S803 1-572-922-11 SWITCH, SLIDE (HOLD .)
S804 1-553-977-00 SWITCH, SLIDE (ESP)
S805 1-771-349-21 SWITCH, TACTILE (VOL –)
S806 1-771-349-21 SWITCH, TACTILE (VOL +)
S807 1-771-349-21 SWITCH, TACTILE (x)
S808 1-771-349-21 SWITCH, TACTILE (> N)
S809 1-771-349-21 SWITCH, TACTILE (.)
S810 1-771-349-21 SWITCH, TACTILE (MENU)
< VARISTOR >
VDR101 1-801-862-11 VARISTOR, CHIP
VDR201 1-801-862-11 VARISTOR, CHIP
VDR301 1-801-862-11 VARISTOR, CHIP
VDR601 1-801-862-11 VARISTOR, CHIP
< VIBRATOR >
X601 1-781-801-11 VIBRATOR, CERAMIC (16.9MHz)
*************************************************************
MISCELLANEOUS
***************
0 101 X-4951-546-1 DAX-11A RP ASSY
111 1-660-965-11 SLIDE FLEXIBLE BOARD
M501 A-3303-403-A MOTOR ASSY, SLED (SLED)
M502 A-3320-788-A MOTOR ASSY, TURN TABLE (SPINDLE)
*************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
1-251-824-12 CONNECTING PACK, CAR (CPA-7) (E206CK)
0 1-467-195-11 ADAPTOR, AC (AC-E455A) (E200/E206CK/E251)
2-201-810-00 TAPE, MAGIC (E206CK)
3-044-618-21 MANUAL, INSTRUCTION (ENGLISH)
3-044-618-31 MANUAL, INSTRUCTION (FRENCH) (CND)
8-916-813-97 CORD DCC-E2455 (E206CK)
8-953-130-90 HEADPHONE MDR-E805LP (E206CK:CND)
8-953-342-98 HEADPHONE, STEREO MDR-24
(EXCEPT E206CK:CND)
