25
D-E221/E223
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
C630 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C631 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C632 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C633 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C634 1-124-434-00 ELECT 220uF 20% 4V
C635 1-115-156-11 CERAMIC CHIP 1uF 10V
C636 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C637 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C638 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C639 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C641 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C642 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C801 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C802 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C803 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C804 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C805 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C806 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C807 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C808 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C809 1-216-864-11 SHORT 0
C810 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C811 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C814 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C815 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C841 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
* CN501 1-815-270-21 CONNECTOR, FFC/FPC (ZIF) 13P
CN502 1-784-342-11 HOUSING, CONNECTOR 2P
CN503 1-784-342-21 HOUSING, CONNECTOR 2P
< DIODE >
D401 8-719-081-83 DIODE CRG01(TE85L)
D402 8-719-073-01 DIODE MA111-(K8).S0
D404 8-719-067-42 DIODE MA2H735-(TX).SO
D405 8-719-072-70 DIODE MA2ZD14001S0
D406 8-719-058-24 DIODE RB501V-40TE-17
D407 8-719-073-01 DIODE MA111-(K8).S0
D408 8-719-072-70 DIODE MA2ZD14001S0
D409 8-719-073-01 DIODE MA111-(K8).S0
D415 8-719-976-96 DIODE DTZ4.7C
D461 8-719-072-70 DIODE MA2ZD14001S0
< COIL >
FB111 1-412-987-31 INDUCTOR 4.7uH
FB211 1-412-987-31 INDUCTOR 4.7uH
FB311 1-412-979-21 INDUCTOR 1uH
FB601 1-500-329-11 INDUCTOR, FERRITE BEAD
FB602 1-216-803-11 METAL CHIP 33 5% 1/16W
FB603 1-412-979-21 INDUCTOR 1uH
FB604 1-216-864-11 SHORT 0
< IC >
IC302 8-759-830-22 IC AN17880A-EAL
IC401 8-759-714-74 IC TB2125F
IC601 8-752-401-56 IC CXD3037R
IC801 8-759-828-36 IC TMP88CM22F-Z3-2
< JACK >
J302 1-815-135-31 JACK, HEADPHONE (i)
J401 1-778-153-21 JACK, DC (POLARITY UNIFIED TYPE)
(DC IN 4.5V)
< COIL >
L401 1-419-544-21 COIL, CHOKE 100uH
L402 1-469-525-91 INDUCTOR 10uH
L408 1-414-400-41 INDUCTOR 22uH
L409 1-469-527-91 INDUCTOR 47uH
L410 1-469-527-91 INDUCTOR 47uH
L411 1-412-054-21 INDUCTOR 2.2uH
L412 1-412-054-21 INDUCTOR 2.2uH
< LIQUID CRYSTAL DISPLAY >
LCD801 1-804-248-11 DISPLAY PANEL, LIQUID CRYSTAL
< TRANSISTOR >
Q401 8-729-921-93 TRANSISTOR 2SB1182F5-QR
Q402 8-729-231-74 TRANSISTOR 2SC4116-GL
Q403 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR
Q404 8-729-425-41 FET 2SK1374-TX (E223)
Q405 8-729-905-40 TRANSISTOR 2SC4081T106
Q406 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR
Q407 8-729-905-40 TRANSISTOR 2SC4081T106
Q408 8-729-029-10 TRANSISTOR DTC143TUA-T106
Q409 8-729-921-73 TRANSISTOR 2SD1781K-T146-QR (E223)
Q410 8-729-922-10 TRANSISTOR 2SA1577-QR
Q411 8-729-905-40 TRANSISTOR 2SC4081T106
Q412 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR
Q413 8-729-427-74 TRANSISTOR XP4601
< RESISTOR >
R1 1-410-993-42 INDUCTOR 1uH
R2 1-216-295-11 SHORT 0
R3 1-216-295-11 SHORT 0
R4 1-216-295-11 SHORT 0
R5 1-216-295-11 SHORT 0
R101 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
(FR)
R101 1-216-837-11 METAL CHIP 22K 5% 1/16W
(EXCEPT FR)
R106 1-216-837-11 METAL CHIP 22K 5% 1/16W
R107 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
(EXCEPT FR)
R107 1-216-839-11 METAL CHIP 33K 5% 1/16W
(FR)
