27
D-E221/E223
Ref. No. Part No. Description Remark
MAIN
R807 1-216-849-11 METAL CHIP 220K 5% 1/16W
(E223)
R809 1-216-845-11 METAL CHIP 100K 5% 1/16W
R810 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R811 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R812 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R813 1-216-839-11 METAL CHIP 33K 5% 1/16W
(EXCEPT FR)
R813 1-216-847-11 METAL CHIP 150K 5% 1/16W
(FR)
R814 1-216-845-11 METAL CHIP 100K 5% 1/16W
R816 1-216-864-11 SHORT 0
R817 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R818 1-216-843-11 METAL CHIP 68K 5% 1/16W
(FR)
R818 1-216-847-11 METAL CHIP 150K 5% 1/16W
(EXCEPT FR)
R819 1-216-845-11 METAL CHIP 100K 5% 1/16W
R820 1-216-821-11 METAL CHIP 1K 5% 1/16W
R821 1-216-841-11 METAL CHIP 47K 5% 1/16W
(E223:FR)
R823 1-216-845-11 METAL CHIP 100K 5% 1/16W
R824 1-216-845-11 METAL CHIP 100K 5% 1/16W
R826 1-216-845-11 METAL CHIP 100K 5% 1/16W
(FR)
R826 1-216-851-11 METAL CHIP 330K 5% 1/16W
(EXCEPT FR)
R829 1-216-864-11 SHORT 0
R830 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R831 1-216-864-11 SHORT 0
R841 1-216-849-11 METAL CHIP 220K 5% 1/16W
< SWITCH >
S801 1-692-440-11 SWITCH, PUSH (OPEN)
S803 1-762-078-11 SWITCH, SLIDE (HOLD .)
S804 1-553-977-00 SWITCH, SLIDE (ESP)
S805 1-692-014-11 SWITCH, KEYBOARD (VOL –)
S806 1-692-014-11 SWITCH, KEYBOARD (VOL +)
S807 1-692-014-11 SWITCH, KEYBOARD (x)
S808 1-692-014-11 SWITCH, KEYBOARD (> N)
S809 1-692-014-11 SWITCH, KEYBOARD (.)
S810 1-771-482-11 SWITCH, PUSH (1 KEY) (SOUND)
S811 1-771-482-11 SWITCH, PUSH (1 KEY) (MENU)
< VARISTOR >
VDR401 1-801-862-11 VARISTOR, CHIP
VDR402 1-801-862-11 VARISTOR, CHIP
VDR601 1-801-862-11 VARISTOR, CHIP
< VIBRATOR >
X601 1-795-101-21 VIBRATOR, CERAMIC (16.9MHz) (E223)
X601 1-795-218-21 VIBRATOR, CERAMIC (16.9MHz) (E221)
*************************************************************
MISCELLANEOUS
***************
0 108 X-4952-506-1 PICK-UP BLOCK, OPTICAL (DAX-23E)
M501 A-3328-627-A MOTOR ASSY, SLED (SLED)
M502 A-3328-759-A MOTOR ASSY, TURNTABLE (SPINDLE)
*************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
0 1-467-007-21 ADAPTOR, AC (AC-E455A) (E221:AUS)
0 1-467-009-21 ADAPTOR, AC (AC-E455D) (E221:E92,MX,TW/
E223:E92)
0 1-467-195-11 ADAPTOR, AC (AC-E454F) (E221:CND)
0 1-473-116-31 ADAPTOR, AC (AC-E455F) (E221:AEP,UK,E13,
G,FR,EE/E223:AEP,G,FR)
0 1-475-969-11 ADAPTOR, AC (AC-E455) (E221:AR)
1-756-158-31 BATTERY PACK (NC-WMAA) (E223)
3-225-997-11 MANUAL, INSTRUCTION (SPANISH)
(E221:AEP,E92,MX,AR)
3-225-997-21 MANUAL, INSTRUCTION (ENGLISH,ARABIC)
(E221:CND,AEP,UK,
E92,AUS,EE,MX,AR)
3-225-997-31 MANUAL, INSTRUCTION (FRENCH)
(E221:CND,AEP,FR)
3-225-997-41 MANUAL, INSTRUCTION (DUTCH)
(E221:AEP,EE)
3-225-997-51 MANUAL, INSTRUCTION (SWEDISH) (E221:AEP)
3-225-997-61 MANUAL, INSTRUCTION (PORTUGUESE)
(E221:AEP,E92,MX,AR)
3-225-997-71 MANUAL, INSTRUCTION (GERMAN)
(E221:AEP,G)
3-225-997-81 MANUAL, INSTRUCTION (ITALIAN) (E221:AEP)
3-225-997-91 MANUAL, INSTRUCTION (FINNISH) (E221:AEP)
3-225-998-11 MANUAL, INSTRUCTION
(TRADITIONAL CHINESE)
(E221:E13,TW)
3-225-998-21 MANUAL, INSTRUCTION (ENGLISH)
(E221:E13,TW)
3-225-999-11 MANUAL, INSTRUCTION (RUSSIAN) (E221:EE)
3-225-999-21 MANUAL, INSTRUCTION (CZECH) (E221:EE)
3-225-999-31 MANUAL, INSTRUCTION (HUNGARIAN)
(E221:EE)
3-225-999-41 MANUAL, INSTRUCTION (POLISH) (E221:EE)
3-225-999-51 MANUAL, INSTRUCTION (SLOVAKIAN)
(E221:EE)
3-227-574-11 MANUAL, INSTRUCTION (SPANISH)
(E223:AEP,E92)
3-227-574-21 MANUAL, INSTRUCTION (ENGLISH)
(E223:AEP,E92)
3-227-574-31 MANUAL, INSTRUCTION (FRENCH)
(E223:AEP,FR)
3-227-574-41 MANUAL, INSTRUCTION (DUTCH) (E223:AEP)
3-227-574-51 MANUAL, INSTRUCTION (SWEDISH) (E223:AEP)
3-227-574-61 MANUAL, INSTRUCTION (PORTUGUESE)
(E223:AEP,E92)
Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
