– 30 –
R824 1-216-833-91 RES-CHIP 10K 5% 1/16W
R826 1-216-841-11 METAL CHIP 47K 5% 1/16W
(FR)
R826 1-216-849-11 METAL CHIP 220K 5% 1/16W
(EXCEPT US)
R826 1-216-851-11 METAL CHIP 330K 5% 1/16W
(US)
R827 1-216-864-11 METAL CHIP 0 5% 1/16W
R829 1-216-819-11 METAL CHIP 680 5% 1/16W
R830 1-216-864-11 METAL CHIP 0 5% 1/16W
R834 1-216-833-91 RES-CHIP 10K 5% 1/16W
(US)
R835 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT US)
R841 1-216-857-11 METAL CHIP 1M 5% 1/16W
R842 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R843 1-216-833-91 RES-CHIP 10K 5% 1/16W
R846 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R901 1-216-811-11 METAL CHIP 150 5% 1/16W
(EJ616CK)
R902 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
(EJ616CK)
R903 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
(EJ616CK)
R904 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
(EJ616CK)
< SWITCH >
S801 1-692-440-11 SWITCH, PUSH (OPEN/CLOSE)
S802 1-762-078-11 SWITCH, SLIDE (AVLS)
S803 1-762-078-11 SWITCH, SLIDE (HOLD .)
S804 1-553-977-00 SWITCH, SLIDE (G PROTECTION)
S805 1-771-482-11 SWITCH, PUSH (1 KEY) (VOLUME + )
S806 1-771-482-11 SWITCH, PUSH (1 KEY) (VOLUME - )
< VARISTOR >
VDR101 1-801-862-11 VARISTOR, CHIP
VDR102 1-801-862-11 VARISTOR, CHIP
VDR201 1-801-862-11 VARISTOR, CHIP
VDR202 1-801-862-11 VARISTOR, CHIP
VDR301 1-801-862-11 VARISTOR, CHIP
VDR303 1-801-862-11 VARISTOR, CHIP
< VIBRATOR >
X601 1-781-690-21 VIBRATOR, CERAMIC (16.9MHz)
**************************************************************
MISCELLANEOUS
**************
13 1-418-612-11 SWITCH UNIT (EJ616CK)
13 1-418-638-11 SWITCH UNIT (EXCEPT EJ616CK)
0 60 X-4952-506-1 OPTICALPICK-UP (DAX-23E)
M901 A-3328-760-A MOTOR ASSY, TURN TABLE (SPINDLE)
M902 A-3328-627-A MOTOR ASSY (SLED)
**************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
1-251-696-11 CONNECTING PACK, CAR (EJ616CK)
1-251-696-21 CONNECTING PACK, CAR (EJ616CK)
1-418-670-11 REMOTE CONTROL UNIT (E660,EJ611:
AR,EJ615)
0 1-467-007-22 ADAPTOR, AC (AC-E455) (AUS)
0 1-467-012-11 ADAPTOR, AC (AC-E455) (EA)
0 1-467-195-12 ADAPTOR, AC (AC-E455A) (US,CND,C&SA)
0 1-467-550-24 ADAPTOR, AC (AC-E455A) (JE,E33)
1-469-089-11 FILTER, CLAMP (FERRITE CORE) (EJ616CK)
0 1-473-115-11 ADAPTOR, AC (AC-E455D) (UK)
0 1-473-116-35 ADAPTOR, AC (AC-E455D)(EJ611:AEP,FR,G,
EE,E13,EJ613/EJ615:AEP,FR,G,EE,E13/
EJ616CK:AEP,EE,G,E13)
0 1-475-622-13 ADAPTOR, AC (AC-E455) (CH)
0 1-475-623-11 ADAPTOR, AC (AC-E455) (HK)
0 1-475-969-11 ADAPTOR, AC (AC-E455) (AR)
1-532-433-11 FUSE, GLASS CYLINDRICAL(DIA.5)(1A)
(EJ616CK)
1-532-577-11 FUSE, GLASS TUBE (1A) (EJ616CK)
1-533-689-11 FUSE, GLASS CYLINDRICAL(DIA.5) (EJ616CK)
0 1-569-007-11 ADAPTOR, CONVERSION 2P (JE,E33)
0 1-569-008-21 ADAPTOR, CONVERSION 2P (EJ611:EA/
EJ616CK:EA)
1-756-035-11 BATTERY PACK (NC-WMAA) (E660,EJ615:
AUS,E13,E33,C&SA,HK,CH)
1-756-035-21 BATTERY PACK (NC-WMAA) (EJ613,EJ615:
AEP,FR,G,EE,UK)
1-756-035-31 BATTERY PACK (NC-WMAA) (EJ615:US,CND)
1-784-619-11 CORD DCC-E2455//M SET (EJ616CK)
3-046-109-11 MANUAL, INSTRUCTION (ENGLISH)
(EJ611:US/EJ615:US)
3-046-318-01 CASE, CARRYING (EJ616CK:US)
3-046-319-01 STRAP (P) (EJ611:US/EJ615:US)
3-046-768-11 MANUAL, INSTRUCTION (ENGLISH)
(EJ616CK:US)
3-868-180-01 MANUAL, INSTRUCTION (JAPANESE,
ENGLISH,CHINESE,KOREA) (E660)
3-868-180-11 MANUAL, INSTRUCTION (SPANISH)
(E660,EJ610:EXCEPT FR,G/EJ611:AEP,E33,C&SA,
EA,AR/EJ613:AEP/EJ615:AEP,E33,C&SA)
3-868-180-21 MANUAL, INSTRUCTION (ENGLISH)
(E660,EJ610:EXCEPT G/EJ611:EXCEPT US,G,
CH,E13/EJ613:AEP,FR/EJ615:
EXCEPT US,G,CH,HK,E13)
3-868-180-31 MANUAL, INSTRUCTION(FRENCH)
(E660,EJ610:EXCEPT G/EJ611:CND,AEP,FR/
EJ613:AEP,FR/EJ615:CND,AEP,FR)
3-868-180-41 MANUAL, INSTRUCTION (DUTCH)(EJ610:
EXCEPT FR,G/EJ611:AEP,EE/EJ613:
AEP/EJ615:AEP,EE)
3-868-180-51 MANUAL, INSTRUCTION (SWEDISH)(EJ610:
EXCEPT FR,G/EJ611:AEP/EJ613:AEP/
EJ615:AEP)
3-868-180-61 MANUAL, INSTRUCTION (PORTUGUESE)
(EJ610:EXCEPT FR,G/EJ611:AEP,C&SA,AR/
EJ613:AEP/EJ615:AEP,C&SA)
3-868-180-71 MANUAL, INSTRUCTION (GERMAN)(EJ610:
EXCEPT FR/EJ611:AEP,G/EJ613:AEP,G/
EJ615:AEP,G)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
MAIN
