NOTE :
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms
METAL : Metal-film resistor
METAL OXIDE :Metal oxide-film resistor
F : nonflammable
• Items marked “ * ”are not stocked since
they are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u : µ , for example :
uA.... : µ A.... , uPA.... : µ PA....
uPB.... : µ PB.... , uPC.... : µ PC....
uPD.... : µ PD....
• CAPACITORS
uF : µ F
• COILS
uH : µ H
Les composants identifiés par une
marque 0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
When indicating parts by reference num-
ber, please include the board.
The components identified by mark 0
or dotted line with mark 0 are critical
for safety.
Replace only with part number specified.
z
ELECTRICAL PARTS LIST (Service Manual see page 26 to 31)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-3323-399-A MAIN BOARD, COMPLETE (EXCEPT US,FR/
EJ616CK)
A-3323-400-A MAIN BOARD, COMPLETE (FR)
A-3323-401-A MAIN BOARD, COMPLETE
(EJ616CK:EXCEPT US)
A-3323-464-A MAIN BOARD, COMPLETE
(EJ611:US/EJ615:US)
A-3323-465-A MAIN BOARD, COMPLETE (EJ616CK:US)
*********************
< BATTERY TERMINAL >
BT400 4-223-585-01 TERMINAL (+), BATTERY
BT402 4-223-584-01 TERMINAL (-), BATTERY
< CAPACITOR >
C101 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C102 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C103 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C104 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C105 1-115-156-11 CERAMIC CHIP 1uF 10V
C106 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C154 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C201 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C202 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C203 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C204 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C205 1-115-156-11 CERAMIC CHIP 1uF 10V
C254 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C300 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C304 1-216-864-11 METAL CHIP 0 5% 1/16W
C312 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C313 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C351 1-115-156-11 CERAMIC CHIP 1uF 10V
C352 1-124-261-00 ELECT 10uF 20% 50V
C353 1-124-261-00 ELECT 10uF 20% 50V
C354 1-128-057-11 ELECT 330uF 20% 6.3V
C400 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C401 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C402 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C403 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C404 1-125-822-11 TANTALUM 10uF 20% 10V
C405 1-115-156-11 CERAMIC CHIP 1uF 10V
C406 1-128-057-11 ELECT 330uF 20% 6.3V
C407 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C408 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C409 1-124-584-00 ELECT 100uF 20% 10V
C410 1-124-584-00 ELECT 100uF 20% 10V
C411 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C412 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C413 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C414 1-162-227-01 CERAMIC CHIP 0.022uF 10% 50V
C415 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C416 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C417 1-110-569-21 TANTAL. CHIP 47uF 20% 4V
C418 1-124-635-00 ELECT 220uF 20% 6.3V
C419 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C420 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C421 1-110-569-21 TANTAL. CHIP 47uF 20% 4V
C422 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C423 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C424 1-165-112-11 CERAMIC CHIP 0.33uF 16V
C425 1-115-156-11 CERAMIC CHIP 1uF 10V
C426 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C427 1-110-569-21 TANTAL. CHIP 47uF 20% 4V
C430 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C431 1-124-234-00 ELECT 22uF 20% 16V
C432 1-125-822-11 TANTALUM 10uF 20% 10V
C433 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C435 1-125-822-11 TANTALUM 10uF 20% 10V
C438 1-115-156-11 CERAMIC CHIP 1uF 10V
C442 1-115-156-11 CERAMIC CHIP 1uF 10V
C446 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C451 1-115-156-11 CERAMIC CHIP 1uF 10V
(US)
C451 1-162-964-11 CERAMIC CHIP 0.001uF 10V
(EXCEPT US)
C453 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C461 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C462 1-162-925-11 CERAMIC CHIP 68PF 5% 50V
C500 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C501 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C502 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
• Abbreviation
CND : Canadian AUS : Australian
FR : French HK : Hong Kong
AR : Argentina JE : Tourist
G : German EA : Saudi Arabia
CH : Chinese EE : East European
MX : Mexican
C&SA : Central and South America
E13 : AC220-230V area model
E33 : AC100-240V area model
MAIN
C602 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C603 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C604 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C605 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C606 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C607 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C609 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C611 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C612 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C613 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C614 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C615 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C616 1-104-847-11 TANTALUM CHIP 22uF 20% 4V
(EXCEPT US)
C618 1-164-505-11 CERAMIC CHIP 2.2uF 16V
(EXCEPT US)
C619 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C620 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C621 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C622 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C623 1-115-156-11 CERAMIC CHIP 1uF 10V
C624 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C625 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C626 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C627 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C628 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C629 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C630 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C631 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C632 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C634 1-124-635-00 ELECT 220uF 20% 6.3V
C635 1-164-505-11 CERAMIC CHIP 2.2uF 10V
C636 1-164-156-11 CERAMIC CHIP 2.2uF 10V
C638 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C639 1-104-847-11 TANTAL. CHIP 22uF 20% 4V (US)
C800 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C801 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C802 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C803 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C804 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C805 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C806 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C807 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C808 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C809 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C810 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C811 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C814 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C841 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C900 1-135-201-11 TANTAL CHIP 10uF 20% 4V
(EJ616CK)
< CONNECTOR >
* CN501 1-793-627-21 CONNECTOR (SMT) 13P
CN502 1-784-342-11 HOUSING, CONNECTOR 2P
CN503 1-784-342-21 HOUSING, CONNECTOR 2P
* CN801 1-793-711-21 CONNECTOR, FFC/FPC (ZIF) 24P
< DIODE >
D300 8-719-069-54 DIODE UDZ5.1B
D301 8-719-069-54 DIODE UDZ5.1B
D302 8-719-069-54 DIODE UDZ5.1B
D401 8-719-077-01 DIODE CRS03
D403 8-719-069-54 DIODE UDZ5.1B
D404 8-719-067-42 DIODE MA2H735-(TX).SO
D405 8-719-072-70 DIODE MA2ZD14001S0
D406 8-719-071-87 DIODE MA785-(TX),SO
D408 8-719-072-70 DIODE MA2ZD14001S0
D409 8-719-976-96 DIODE UDZ-TE-17-4.7B
D410 8-719-069-54 DIODE UDZ5.1B
D461 8-719-072-70 DIODE MA2ZD14001S0
D601 8-719-044-74 DIODE MA792WK-TX
D602 8-719-073-01 DIODE MA111-(K8).SO (US)
D603 8-719-069-54 DIODE UDZ5.1B
D804 8-719-069-54 DIODE UDZ5.1B
D805 8-719-069-54 DIODE UDZ5.1B
D901 8-719-077-01 DIODE CRS03 (EJ616CK)
< FERRITE BEAD >
FB101 1-412-985-31 INDUCTOR 3.3uH
FB111 1-412-987-31 INDUCTOR 4.7uH
FB201 1-412-985-31 INDUCTOR 3.3uH
FB211 1-412-987-31 INDUCTOR 4.7uH
FB301 1-412-985-31 INDUCTOR 3.3uH
FB311 1-412-987-31 INDUCTOR 4.7uH
FB312 1-412-979-21 INDUCTOR 1uH
FB602 1-216-803-11 RESISTOR, CHIP 33 5% 1/16W
FB603 1-412-979-21 INDUCTOR 1uH
< IC >
IC302 8-759-522-87 IC TA2120FN(EL)
IC310 8-759-525-27 IC TC7W66FU
IC401 8-759-642-56 IC TB2119F
IC402 8-759-651-13 IC NJU7116F (TE2)
IC404 8-759-651-13 IC NJU7116F (TE2)
IC601 8-752-398-18 IC CXD3027R (US)
IC601 8-752-401-56 IC CXD3037R (EXCEPT US)
IC602 8-759-538-44 IC MSM51V17400D-10TK-FS (US)
IC801 8-759-649-81 IC TMP88CM22F-1A54 (EXCEPT US,FR)
IC801 8-759-649-82 IC TMP88CM22-1A56 (FR/EJ611:US/
EJ615:US)
IC801 8-759-649-83 IC TMP88CM22F-1A92(EJ616CK:US)
< JACK >
J301 1-778-696-11 JACK (LINE OUT)
J302 1-580-680-11 JACK ( i /REMOTE)
J401 1-778-153-21 JACK,DC(POLARITY UNIFIED TYPE)
(DC IN 4.5V)
< COIL >
L311 1-412-002-31 INDUCTOR 4.7uH
L401 1-419-188-21 INDUCTOR 100uH
L402 1-469-525-91 INDUCTOR 10uH
L403 1-414-434-11 INDUCTOR 100uH
L404 1-469-528-91 INDUCTOR 100uH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
L405 1-469-525-91 INDUCTOR 10uH
L406 1-414-404-11 INDUCTOR 100uH
L407 1-469-525-91 INDUCTOR 10uH
L408 1-414-400-11 INDUCTOR 22uH
L409 1-469-527-91 INDUCTOR 47uH (US)
L409 1-469-757-11 INDUCTOR 100uH (EXCEPT US)
L410 1-469-527-91 INDUCTOR 47uH
L411 1-414-394-11 INDUCTOR 2.2uH (US)
L411 1-412-002-31 INDUCTOR 4.7uH (EXCEPT US)
L412 1-414-392-21 INDUCTOR 1uH
L601 1-412-002-31 INDUCTOR 4.7uH
< TRANSISTOR >
Q301 8-729-043-90 TRANSISTOR IMX9T110
Q302 8-729-930-00 TRANSISTOR UMD2-TL
Q401 8-729-050-17 TRANSISTOR 2SA1241-Y
Q402 8-729-920-82 TRANSISTOR 2SB1188-QR
Q403 8-729-921-73 TRANSISTOR 2SD1781K-T146-QR
Q404 8-729-425-41 TRANSISTOR 2SK1374-TX
Q405 8-729-047-36 TRANSISTOR CPH3303-TL
Q406 8-729-904-86 TRANSISTOR 2SB1197K-T-146-Q
Q407 8-729-029-14 TRANSISTOR DTC144EUA-T106
Q408 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR
Q409 8-729-231-74 TRANSISTOR 2SC4116-GL
Q411 8-729-429-44 TRANSISTOR XP1501-TXE
Q412 8-729-904-86 TRANSISTOR 2SB1197K-T-146-Q
Q500 8-729-028-74 TRANSISTOR DTA114TUA-T106
Q900 8-729-429-44 TRANSISTOR XP1501-TXE (EJ616CK)
Q902 8-729-920-82 TRANSISTOR 2SB1188-QR (EJ616CK)
Q904 8-729-028-76 TRANSISTOR DTA114YUA-T106 (EJ616CK)
< RESISTOR >
R1 1-216-864-11 METAL CHIP 0 5% 1/16W
R2 1-216-864-11 METAL CHIP 0 5% 1/16W
R101 1-216-813-11 METAL CHIP 220 5% 1/16W
R102 1-218-875-11 METAL CHIP 15K 0.5% 1/16W
R103 1-218-871-11 RES-CHIP 10K 0.5% 1/16W
R104 1-218-871-11 RES-CHIP 10K 0.5% 1/16W
R105 1-216-821-11 METAL CHIP 1K 5% 1/16W
R106 1-216-845-11 METAL CHIP 100K 5% 1/16W
R107 1-216-837-11 METAL CHIP 22K 5% 1/16W
R109 1-216-843-11 METAL CHIP 68K 5% 1/16W
(EXCEPT US)
R110 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R111 1-216-847-11 METAL CHIP 150K 5% 1/16W
(EXCEPT US,FR)
R111 1-216-823-91 METAL CHIP 1.5K 5% 1/16W
(FR)
R111 1-216-835-11 METAL CHIP 15K 5% 1/16W
(US)
R153 1-216-809-11 METAL CHIP 100 5% 1/16W
R154 1-216-793-11 RES-CHIP 4.7 5% 1/16W
R201 1-216-813-11 METAL CHIP 220 5% 1/16W
R202 1-218-875-11 METAL CHIP 15K 0.5% 1/16W
R203 1-218-871-11 RES-CHIP 10K 0.5% 1/16W
R204 1-218-871-11 RES-CHIP 10K 0.5% 1/16W
R205 1-216-821-11 METAL CHIP 1K 5% 1/16W
R206 1-216-845-11 METAL CHIP 100K 5% 1/16W
R207 1-216-837-11 METAL CHIP 22K 5% 1/16W
R209 1-216-843-11 METAL CHIP 68K 5% 1/16W
(EXCEPT US)
R210 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R211 1-216-847-11 METAL CHIP 150K 5% 1/16W
(EXCEPT US,FR)
R211 1-216-823-91 METAL CHIP 1.5K 5% 1/16W
(FR)
R211 1-216-835-11 METAL CHIP 15K 5% 1/16W
(US)
R253 1-216-809-11 METAL CHIP 100 5% 1/16W
R254 1-216-793-11 RES-CHIP 4.7 5% 1/16W
R315 1-218-871-11 METAL CHIP 10K 0.5% 1/16W
R316 1-216-821-11 METAL CHIP 1K 5% 1/16W
R319 1-216-296-91 METAL CHIP 0 5% 1/8W
R320 1-216-296-91 METAL CHIP 0 5% 1/8W
R321 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT US)
R322 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT US)
R353 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R401 1-216-861-11 METAL CHIP 2.2M 5% 1/16W
R402 1-216-833-91 RES-CHIP 10K 5% 1/16W
R403 1-216-853-11 METAL CHIP 470K 5% 1/16W
R408 1-216-853-11 METAL CHIP 470K 5% 1/16W
R409 1-216-849-11 METAL CHIP 220K 5% 1/16W
R410 1-216-843-11 METAL CHIP 68K 5% 1/16W
R415 1-216-833-91 RES-CHIP 10K 5% 1/16W
R416 1-216-857-11 METAL CHIP 1M 5% 1/16W
R417 1-216-864-11 METAL CHIP 0 5% 1/16W
R418 1-218-895-11 METAL CHIP 100K 0.5% 1/16W
R419 1-218-903-11 METAL CHIP 220K 0.5% 1/16W
R420 1-216-864-11 METAL CHIP 0 5% 1/16W
R421 1-216-857-11 METAL CHIP 1M 5% 1/16W
R422 1-216-835-11 METAL CHIP 15K 5% 1/16W
R423 1-216-839-11 METAL CHIP 33K 5% 1/16W
R424 1-216-833-91 RES-CHIP 10K 5% 1/16W
R426 1-216-837-11 METAL CHIP 22K 5% 1/16W
R427 1-216-815-11 METAL CHIP 330 5% 1/16W
R429 1-216-857-11 METAL CHIP 1M 5% 1/16W
(US)
R430 1-216-041-00 METAL CHIP 470 5% 1/10W
R431 1-216-864-11 METAL CHIP 0 5% 1/16W
R432 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R434 1-218-899-11 METAL CHIP 150K 0.5% 1/16W
(EXCEPT US)
R434 1-218-903-11 METAL CHIP 220K 0.5% 1/16W
(US)
R435 1-218-887-11 METAL CHIP 47K 0.5% 1/16W
R436 1-216-864-11 METAL CHIP 0 5% 1/16W
R437 1-216-861-11 METAL CHIP 2.2M 5% 1/16W
R439 1-216-859-11 RES-CHIP 1.5M 5% 1/16W
R440 1-216-861-11 METAL CHIP 2.2M 5% 1/16W
R442 1-216-817-11 METAL CHIP 470 5% 1/16W
R443 1-216-811-11 METAL CHIP 150 5% 1/16W
R446 1-216-821-11 METAL CHIP 1K 5% 1/16W
R447 1-216-304-11 METAL CHIP 3.3 5% 1/10W
R448 1-216-298-00 METAL CHIP 2.2 5% 1/10W
R449 1-216-298-00 METAL CHIP 2.2 5% 1/10W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
R450 1-216-845-11 METAL CHIP 100K 5% 1/16W
R451 1-218-903-11 METAL CHIP 220K 0.5% 1/16W
R452 1-218-887-11 METAL CHIP 47K 0.5% 1/16W
R453 1-218-887-11 METAL CHIP 47K 0.5% 1/16W
R454 1-218-887-11 METAL CHIP 47K 0.5% 1/16W
R455 1-216-839-11 METAL CHIP 33K 5% 1/16W
R456 1-216-857-11 METAL CHIP 1M 5% 1/16W
R457 1-216-859-11 RES-CHIP 1.5M 5% 1/16W
R461 1-218-895-11 METAL CHIP 100K 0.5% 1/16W
R462 1-218-887-11 METAL CHIP 47K 0.5% 1/16W
R463 1-216-857-11 METAL CHIP 1M 5% 1/16W
R464 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R471 1-216-864-11 METAL CHIP 0 5% 1/16W
R602 1-216-845-11 METAL CHIP 100K 5% 1/16W
(EXCEPT US)
R603 1-216-851-11 METAL CHIP 330K 5% 1/16W
R604 1-216-857-11 METAL CHIP 1M 5% 1/16W
R605 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R606 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R607 1-216-833-91 RES-CHIP 10K 5% 1/16W
R608 1-216-853-11 METAL CHIP 470K 5% 1/16W
R609 1-216-833-91 RES-CHIP 10K 5% 1/16W
R610 1-216-864-11 METAL CHIP 0 5% 1/16W
R611 1-216-837-11 METAL CHIP 22K 5% 1/16W
R612 1-216-841-11 METAL CHIP 47K 5% 1/16W
R613 1-216-837-11 METAL CHIP 22K 5% 1/16W
R614 1-216-845-11 METAL CHIP 100K 5% 1/16W
R615 1-216-837-11 METAL CHIP 22K 5% 1/16W
R616 1-216-845-11 METAL CHIP 100K 5% 1/16W
R617 1-216-837-11 METAL CHIP 22K 5% 1/16W
R619 1-216-837-11 METAL CHIP 22K 5% 1/16W
R621 1-216-864-11 METAL CHIP 0 5% 1/16W
R623 1-216-819-11 METAL CHIP 680 5% 1/16W
R624 1-216-845-11 METAL CHIP 100K 5% 1/16W
R625 1-216-833-91 RES-CHIP 10K 5% 1/16W
R626 1-216-819-11 METAL CHIP 680 5% 1/16W
R627 1-216-819-11 METAL CHIP 680 5% 1/16W
R629 1-216-833-91 RES-CHIP 10K 5% 1/16W
R630 1-216-823-91 METAL CHIP 1.5K 5% 1/16W
R632 1-216-839-11 METAL CHIP 33K 5% 1/16W
R633 1-216-845-11 METAL CHIP 100K 5% 1/16W
(EXCEPT US)
R634 1-216-805-11 METAL CHIP 47 5% 1/16W
(EXCEPT US)
R634 1-216-807-11 METAL CHIP 68 5% 1/16W
(US)
R636 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT US)
R638 1-216-864-11 METAL CHIP 0 5% 1/16W
R639 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT US)
R640 1-216-819-11 METAL CHIP 680 5% 1/16W
R641 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT US)
R642 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT US)
R643 1-216-864-11 METAL CHIP 0 5% 1/16W
(US)
R644 1-216-819-11 METAL CHIP 680 5% 1/16W
R645 1-216-819-11 METAL CHIP 680 5% 1/16W
R646 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT US)
R647 1-216-833-91 RES-CHIP 10K 5% 1/16W
R648 1-216-833-91 RES-CHIP 10K 5% 1/16W
R649 1-216-833-91 RES-CHIP 10K 5% 1/16W
R653 1-216-864-11 METAL CHIP 0 5% 1/16W
R654 1-216-864-11 METAL CHIP 0 5% 1/16W
R655 1-216-864-11 METAL CHIP 0 5% 1/16W
R801 1-216-845-11 METAL CHIP 100K 5% 1/16W
R802 1-216-845-11 METAL CHIP 100K 5% 1/16W
R803 1-216-843-11 METAL CHIP 68K 5% 1/16W
R805 1-216-809-11 METAL CHIP 100 5% 1/16W
R807 1-216-845-11 METAL CHIP 100K 5% 1/16W
(FR)
R807 1-216-851-11 METAL CHIP 330K 5% 1/16W
(EXCEPT FR)
R809 1-216-845-11 METAL CHIP 100K 5% 1/16W
R811 1-216-864-11 METAL CHIP 0 5% 1/16W
R812 1-216-864-11 METAL CHIP 0 5% 1/16W
R813 1-216-837-11 METAL CHIP 22K 5% 1/16W
(US)
R813 1-216-839-11 METAL CHIP 33K 5% 1/16W
(EXCEPT US,FR)
R813 1-216-847-11 METAL CHIP 150K 5% 1/16W
(FR)
R814 1-216-845-11 METAL CHIP 100K 5% 1/16W
R818 1-216-843-11 METAL CHIP 68K 5% 1/16W
(FR)
R818 1-216-847-11 METAL CHIP 150K 5% 1/16W
(EXCEPT US,FR)
R821 1-216-864-11 METAL CHIP 0 5% 1/16W
R823 1-216-833-91 RES-CHIP 10K 5% 1/16W
R824 1-216-833-91 RES-CHIP 10K 5% 1/16W
R826 1-216-841-11 METAL CHIP 47K 5% 1/16W
(FR)
R826 1-216-849-11 METAL CHIP 220K 5% 1/16W
(EXCEPT US,FR)
R826 1-216-851-11 METAL CHIP 330K 5% 1/16W
(US)
R827 1-216-864-11 METAL CHIP 0 5% 1/16W
R829 1-216-819-11 METAL CHIP 680 5% 1/16W
R830 1-216-864-11 METAL CHIP 0 5% 1/16W
R834 1-216-833-91 RES-CHIP 10K 5% 1/16W
(US)
R835 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT US)
R836 1-216-295-91 METAL CHIP 0 5% 1/10W
R837 1-216-295-91 METAL CHIP 0 5% 1/10W
R838 1-216-295-91 METAL CHIP 0 5% 1/10W
R841 1-216-857-11 METAL CHIP 1M 5% 1/16W
R842 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R843 1-216-833-91 RES-CHIP 10K 5% 1/16W
R846 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R901 1-216-811-11 METAL CHIP 150 5% 1/16W
(EJ616CK)
R902 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
(EJ616CK)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
To Next Page
Loading...
