10
D-E660/EJ610/EJ611/EJ613/EJ615/EJ616CK
NOTE :
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms
METAL : Metal-film resistor
METAL OXIDE :Metal oxide-film resistor
F : nonflammable
• Items marked “ * ”are not stocked since
they are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u : µ , for example :
uA.... : µ A.... , uPA.... : µ PA....
uPB.... : µ PB.... , uPC.... : µ PC....
uPD.... : µ PD....
• CAPACITORS
uF : µ F
• COILS
uH : µ H
Les composants identifiés par une
marque 0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
When indicating parts by reference num-
ber, please include the board.
The components identified by mark 0
or dotted line with mark 0 are critical
for safety.
Replace only with part number specified.
z
ELECTRICAL PARTS LIST (SERVICE MANUAL SEE PAGE 26 TO 31)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
A-3323-589-A MAIN BOARD, COMPLETE
(EXCEPT US, FR/EJ616CK)
*******************
3-047-194-01 SHEET (CDM), ADHESIVE
3-831-441-99 CUSHION, STOPPER
4-223-586-01 TERMINAL BOARD (RELAY),BATTERY
<BATTERY TERMINAL>
BT400 4-223-585-01 TERMINAL BOARD (+), BATTERY
BT402 4-223-584-01 TERMINAL BOARD (-), BATTERY
<CAPACITOR>
C101 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C102 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C103 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C104 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C105 1-115-156-11 CERAMIC CHIP 1uF 10V
C106 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C154 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C201 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C202 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C203 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C204 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C205 1-115-156-11 CERAMIC CHIP 1uF 10V
C254 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C300 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C304 1-216-864-11 METAL CHIP 0 5% 1/16W
C312 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C313 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C351 1-115-156-11 CERAMIC CHIP 1uF 10V
C352 1-124-261-00 ELECT 10uF 20% 50V
C353 1-124-261-00 ELECT 10uF 20% 50V
C354 1-128-057-11 ELECT 330uF 20% 6.3V
C400 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C401 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C402 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C403 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C404 1-125-822-11 TANTALUM 10uF 20% 10V
C405 1-115-156-11 CERAMIC CHIP 1uF 10V
C406 1-128-057-11 ELECT 330uF 20% 6.3V
C407 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C408 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C409 1-124-584-00 ELECT 100uF 20% 10V
C410 1-124-584-00 ELECT 100uF 20% 10V
C411 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C412 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C413 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C414 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C415 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C416 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C417 1-110-569-21 TANTAL. CHIP 47uF 20% 4V
C418 1-124-635-00 ELECT 220uF 20% 6.3V
C419 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C420 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C421 1-110-569-21 TANTAL. CHIP 47uF 20% 4V
C422 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C423 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C424 1-165-112-11 CERAMIC CHIP 0.33uF 16V
C425 1-115-156-11 CERAMIC CHIP 1uF 10V
C426 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C427 1-110-569-21 TANTAL. CHIP 47uF 20% 4V
C429 1-216-857-11 METAL CHIP 1M 5% 1/16W
C430 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C431 1-124-234-00 ELECT 22uF 20% 16V
C432 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C433 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C435 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C438 1-115-156-11 CERAMIC CHIP 1uF 10V
C442 1-115-156-11 CERAMIC CHIP 1uF 10V
C446 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C451 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C453 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C461 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C462 1-162-925-11 CERAMIC CHIP 68PF 5% 50V
C500 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C501 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C502 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C602 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C603 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C604 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C605 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C606 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C607 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C609 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C611 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
To Next Page
