18
D-EJ011
SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA... : µA... uPA... : µPA...
uPB... : µPB... uPC... : µPC...
uPD... : µPD...
• CAPACITORS
uF: µF
• COILS
uH: µH
When indicating parts by reference
number, please include the board.
The components identified by mark
0 or dotted line with mark 0 are
critical for safety.
Replace only with part number
specified.
A-1220-717-A MAIN BOARD, COMPLETE
********************
2-887-108-01 TERMINAL (+), BATTERY
2-887-109-01 TERMINAL (–), BATTERY
< CAPACITOR >
C101 1-100-581-81 CERAMIC CHIP 0.0047uF 10% 50V
C102 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C104 1-124-635-00 ELECT 220uF 20% 6.3V
C105 1-126-794-11 ELECT 4.7uF 20% 50V
C108 1-164-935-11 CERAMIC CHIP 470PF 10% 50V
C110 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C201 1-100-581-81 CERAMIC CHIP 0.0047uF 10% 50V
C202 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C204 1-124-635-00 ELECT 220uF 20% 6.3V
C205 1-126-794-11 ELECT 4.7uF 20% 50V
C208 1-164-935-11 CERAMIC CHIP 470PF 10% 50V
C210 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C303 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C304 1-126-382-11 ELECT 100uF 20% 16V
C305 1-126-513-11 ELECT 47uF 20% 6.3V
C306 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C401 1-100-352-91 CERAMIC CHIP 1uF 20% 16V
C403 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C404 1-126-791-11 ELECT 10uF 20% 35V
C405 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C406 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C408 1-126-382-11 ELECT 100uF 20% 16V
C409 1-126-791-11 ELECT 10uF 20% 35V
C410 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C411 1-164-935-11 CERAMIC CHIP 470PF 10% 50V
C412 1-115-156-11 CERAMIC CHIP 1uF 10V
C413 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C416 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C417 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C419 1-124-635-00 ELECT 220uF 20% 6.3V
C420 1-124-635-00 ELECT 220uF 20% 6.3V
C601 1-126-513-11 ELECT 47uF 20% 6.3V
C602 1-126-513-11 ELECT 47uF 20% 6.3V
C603 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C604 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C605 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C606 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C607 1-126-513-11 ELECT 47uF 20% 6.3V
C609 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C610 1-126-794-11 ELECT 4.7uF 20% 50V
C611 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C612 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C613 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C614 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C615 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C618 1-164-935-11 CERAMIC CHIP 470PF 10% 50V
C619 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C620 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C623 1-119-941-41 ELECT 470uF 20% 6.3V
C624 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C625 1-165-884-91 CERAMIC CHIP 2.2uF 10% 6.3V
C626 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C627 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C628 1-126-791-11 ELECT 10uF 20% 35V
C629 1-165-884-91 CERAMIC CHIP 2.2uF 10% 6.3V
C630 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C802 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C803 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C804 1-802-068-21 VARISTOR, CHIP (1608)
C805 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C806 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C807 1-115-156-11 CERAMIC CHIP 1uF 10V
C808 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C809 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C811 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
CB414 1-112-557-11 CERAMIC CHIP 0.022uF 20% 16V
< CONNECTOR >
CN501 1-774-975-51 CONNECTOR, FFC/FPC 16P
< DIODE >
D401 8-719-422-58 DIODE MA8062
D403 8-719-085-43 DIODE MA2YD2300LS0
D404 8-719-083-82 DIODE UDZS-TE17-12B
D803 8-719-404-50 DIODE MA111-TX
< FUSE >
0F401 1-576-415-21 FUSE 2A 32V
0F402 1-576-415-21 FUSE 2A 32V
MAIN
• Abbreviation
KR : korea model
