D-EJ011
SECTION 3
DISASSEMBLY
• This set can be disassembled in the order shown below.
3-1. DISASSEMBLY FLOW
3-2. CABINET (INNER) ASSY, CABINET (LOWER) ASSY
Note: Follow the disassembly procedure in the numerical order given.
3-2. CABINET (INNER) ASSY,
CABINET (LOWER) ASSY
(Page 4)
3-3. OPTICAL PICK-UP (CDM-3525A),
MAIN BOARD
(Page 5)
SET
4 two screws
cabinet (inner) ass
y
cabinet (lower) assy
3 five screws
1
2
5 two claws
6 two claws
