24
D-EJ119/EJ120/EJ121
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
MAIN
C801 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C802 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C803 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C804 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C805 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C806 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C807 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C808 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C809 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C810 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C811 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C812 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C813 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C814 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C815 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1000 1-414-760-21 FERRITE, EMI (SMD) (1608)
< CONNECTOR >
CN401 1-784-342-21 HOUSING, CONNECTOR 2P
CN402 1-785-877-21 HOUSING, CONNECTOR 4P
CN601 1-818-127-11 CONNECTOR, FFC/FPC (ZIF) 15P
CN802 1-815-031-11 FFC/CONNECTOR, FPC (ZIF) 24P
< DIODE >
D101 8-719-083-04 DIODE RSB6.8STE61
D201 8-719-083-04 DIODE RSB6.8STE61
D301 8-719-080-28 DIODE KDZ5.1V
(EJ120: EXCEPT US, E/EJ121: 4E18, MX)
D302 8-719-080-28 DIODE KDZ5.1V
(EJ120: EXCEPT US, E/EJ121: 4E18, MX)
D303 8-719-083-04 DIODE RSB6.8STE61
D304 8-719-989-03 DIODE DAN222
D306 8-719-080-28 DIODE KDZ5.1V
(EJ120: EXCEPT US, E/EJ121: 4E18, MX)
D402 8-719-081-34 DIODE RB160M-30TR
D403 8-719-085-43 DIODE MA2YD2300LS0
D404 8-719-083-02 DIODE KDS160-RTK
D405 8-719-081-34 DIODE RB160M-30TR
D407 8-719-083-02 DIODE KDS160-RTK
D408 8-719-080-28 DIODE KDZ5.1V
D409 8-719-083-02 DIODE KDS160-RTK
D410 8-719-083-04 DIODE RSB6.8STE61
D601 8-719-083-04 DIODE RSB6.8STE61
D802 8-719-072-70 DIODE MA2ZD14001S0
D803 8-719-080-28 DIODE KDZ5.1V
D805 8-719-083-04 DIODE RSB6.8STE61
< FERRITE BEAD >
FB301 1-216-295-91 SHORT CHIP 0
(EJ119/EJ120: US, E/EJ121: E18, EA, AUS, TW)
FB301 1-414-813-11 FERRITE, EMI (SMD) (2012)
(EJ120: EXCEPT US, E/EJ121: 4E18, MX)
FB302 1-414-813-11 FERRITE, EMI (SMD) (2012)
(EJ120: EXCEPT US, E/EJ121: 4E18, MX)
< IC >
IC301 8-759-522-87 IC TA2120FN (EL)
IC403 6-703-034-01 IC BH6580KV
IC601 6-803-922-01 IC BU9354CKV
IC602 6-704-730-01 IC MSM51X4400E-10TSK-F (EXCEPT US, CND)
IC603 6-704-280-01 IC 41SV44052-100TG (US, CND)
IC801 6-803-923-05 IC T5AW5-5GA5
< JACK >
J302 1-816-153-61 JACK (i) (EJ120: EXCEPT US, E/
EJ121: 4E18, MX)
J302 1-818-051-11 JACK (i)
(EJ119/EJ120: US, E/EJ121: E18, EA, AUS, TW)
J401 1-778-153-51 JACK, DC (POLARITY UNIFIED TYPE)
(DC IN 4.5V)
< COIL >
L401 1-400-373-21 INDUCTOR 4.7uH
L402 1-400-373-21 INDUCTOR 4.7uH
L403 1-400-145-21 INDUCTOR 47uH
L404 1-400-388-21 INDUCTOR 220uH
L406 1-400-145-21 INDUCTOR 47uH
L407 1-419-387-21 INDUCTOR 100uH
L409 1-400-145-21 INDUCTOR 47uH
L411 1-400-387-21 INDUCTOR 47uH
L601 1-400-389-21 INDUCTOR 10uH
< TRANSISTOR >
Q402 8-729-106-60 TRANSISTOR 2SB1115A-YQ
Q403 8-729-602-21 TRANSISTOR 2SC4154-F
Q404 6-551-197-01 TRANSISTOR KTA2015Y-RTK
Q406 8-729-602-36 TRANSISTOR 2SA1602-F
Q407 8-729-054-58 TRANSISTOR KTC4075YGR-RTK
Q601 6-551-197-01 TRANSISTOR KTA2015Y-RTK
< RESISTOR >
R101 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R102 1-216-833-11 METAL CHIP 10K 5% 1/10W
R103 1-216-833-11 METAL CHIP 10K 5% 1/10W
R104 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R107 1-216-833-11 METAL CHIP 10K 5% 1/10W
R201 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R202 1-216-833-11 METAL CHIP 10K 5% 1/10W
R203 1-216-833-11 METAL CHIP 10K 5% 1/10W
R204 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R207 1-216-833-11 METAL CHIP 10K 5% 1/10W
R313 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EJ119/EJ120: US, E/EJ121: E18, EA, AUS, TW)
R313 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
(EJ120: EXCEPT US, E/EJ121: 4E18, MX)
R314 1-216-821-11 METAL CHIP 1K 5% 1/10W
(EJ120: EXCEPT US, E/EJ121: 4E18, MX)
R314 1-216-864-11 SHORT CHIP 0
(EJ119/EJ120: US, E/EJ121: E18, EA, AUS, TW)
R322 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R323 1-216-789-11 METAL CHIP 2.2 5% 1/10W
(EJ119/EJ120: EXCEPT US, CND, E)
R324 1-216-789-11 METAL CHIP 2.2 5% 1/10W
(EJ119/EJ120: EXCEPT US, CND, E)
R401 1-216-797-11 METAL CHIP 10 5% 1/10W
R405 1-216-864-11 SHORT CHIP 0
R409 1-216-789-11 METAL CHIP 2.2 5% 1/10W
Ver. 1.3
