D-NE20/NE20LS
3-4. EGH BOARD, JACK BOARD, JACK SUB BOARD, CD MECHANISM DECK (CDM-3325ERV)
4
6
EGH board
7
two insulators
7
insulator
8
CD mechanism deck
(CDM-3325ERV)
5
flexible board (CN601)
0
JACK board
qg
JACK SUB board
qf
three claws
assembly: the cable pass on three claws.
2
connector (2pin)
1
connector (4pin)
3
connector (3pin)
qd
SUB board
(battery terminal board (+))
qa
battery terminal
board (–)
9
Remove solder of the JACK board.
