Sony D-NE20 - Printed Wiring Board - JACK Board (Side A), JACK SUB Board, SUB Board

1919
D-NE20/NE20LS
D-NE20/NE20LS
5-7. PRINTED WIRING BOARD – JACK BOARD (SIDE A), JACK SUB BOARD, SUB BOARD –
:Uses unleaded solder.
IC401
JACK BOARD (SIDE A)
S501
(OPEN/CLOSE)
D501
TP9007
OPR
J301
2 / LINE OUT
(OPTICAL)
A
EGH BOARD
CN9001
(Page 14)
M901
SPINDLE
MOTOR
M902
SLED
MOTOR
J402
(FOR STAND CHARGER)
SUB BOARD
RECHARGEABLE
BATTERY
NH-14WM
1.2V 1350mAh
JACK SUB BOARD
J401
(FOR STAND CHARGER)
1-864-412-
(11)
11
1-864-413-
(11)
11
1-864-411-
(11)
11
D401
1
3
6
4
• Semiconductor
Location
Ref. No. Location
D401 F-8
D402 E-8
D501 A-3
D901 B-3
D903 C-3
D905 F-7
D906 F-8
IC401 E-7
Q301 B-4
Q302 C-4
Q306 B-3
Q307 B-3
Q401 E-7
Q402 F-8
Q403 E-6
