D-NE20/NE20LS
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R612 1-218-977-11 RES-CHIP 100K 5% 1/16W
R613 1-218-990-11 SHORT CHIP 0
R614 1-218-990-11 SHORT CHIP 0
R615 1-218-981-11 RES-CHIP 220K 5% 1/16W
R616 1-218-985-11 RES-CHIP 470K 5% 1/16W
R617 1-218-965-11 RES-CHIP 10K 5% 1/16W
R618 1-218-953-11 RES-CHIP 1K 5% 1/16W
R619 1-400-461-21 FERRITE, EMI (SMD) (1005)
R620 1-218-973-11 RES-CHIP 47K 5% 1/16W
R621 1-218-953-11 RES-CHIP 1K 5% 1/16W
R622 1-218-981-11 RES-CHIP 220K 5% 1/16W
(AEP, UK, EE)
R623 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R624 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R625 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R628 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R629 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R634 1-218-965-11 RES-CHIP 10K 5% 1/16W
R635 1-218-989-11 RES-CHIP 1M 5% 1/16W
R636 1-218-977-11 RES-CHIP 100K 5% 1/16W
R637 1-218-981-11 RES-CHIP 220K 5% 1/16W
R639 1-218-973-11 RES-CHIP 47K 5% 1/16W
R642 1-218-973-11 RES-CHIP 47K 5% 1/16W
R644 1-218-937-11 RES-CHIP 47 5% 1/16W
R649 1-218-969-11 RES-CHIP 22K 5% 1/16W
R650 1-218-977-11 RES-CHIP 100K 5% 1/16W
R651 1-218-977-11 RES-CHIP 100K 5% 1/16W
R653 1-218-965-11 RES-CHIP 10K 5% 1/16W
R655 1-218-977-11 RES-CHIP 100K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB601 1-233-969-11 RES, NETWORK (CHIP TYPE) 22K
< VIBRATOR >
X601 1-813-314-11 VIBRATOR, CRYSTAL 22.579MHz
*************************************************************
A-1076-646-A JACK BOARD, COMPLETE (JE, KR)
A-1098-010-A JACK BOARD, COMPLETE (US, CND)
A-1098-011-A JACK BOARD, COMPLETE (E18, EA, AUS, CH)
A-1113-456-A JACK BOARD, COMPLETE (AEP, EE, UK)
*************************************
2-187-575-01 TERMINAL (–), BATTERY
< CAPACITOR >
C101 1-165-884-91 CERAMIC CHIP 2.2uF 10% 6.3V
C103 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C201 1-165-884-91 CERAMIC CHIP 2.2uF 10% 6.3V
C203 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C301 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C302 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C304 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C305 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C306 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C402 1-115-156-11 CERAMIC CHIP 1uF 10V
C403 1-128-829-91 TANTAL. CHIP 220uF 20% 6.3V
C404 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C406 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C407 1-164-935-11 CERAMIC CHIP 470PF 10% 50V
C409 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C801 1-164-933-11 CERAMIC CHIP 220PF 10% 50V
C802 1-164-933-11 CERAMIC CHIP 220PF 10% 50V
C901 1-115-156-11 CERAMIC CHIP 1uF 10V
C903 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN401 1-770-620-21 PIN, CONNECTOR 3P
CN601 1-785-877-21 HOUSING, CONNECTOR 4P
CN602 1-784-342-21 HOUSING, CONNECTOR 2P
CN9002 1-818-843-11 CONNECTOR, BOARD TO BOARD 50P
< DIODE >
D401 6-500-483-01 DIODE MA22D2800LS0
D402 8-719-085-43 DIODE MA2YD2300LS0
D501 6-500-191-01 DIODE BRPG1211F-TR (OPR)
D901 8-719-077-43 DIODE MAZZ068H01S0
D902 8-719-083-04 DIODE RSB6.8STE61
D903 8-719-083-04 DIODE RSB6.8STE61
D904 8-719-422-37 DIODE MA8051-TX
D905 8-719-422-37 DIODE MA8051-TX
D906 8-719-083-04 DIODE RSB6.8STE61
< FUSE >
0 F401 1-576-406-21 FUSE 1.4A/32V
< FERRITE BEAD >
FB401 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
FB402 1-216-864-11 SHORT CHIP 0
FB801 1-414-813-11 FERRITE, EMI (SMD) (2012)
FB802 1-216-295-91 SHORT CHIP 0 (US, CND)
FB802 1-414-813-11 FERRITE, EMI (SMD) (2012) (EXCEPT US, CND)
FB803 1-414-813-11 FERRITE, EMI (SMD) (2012)
FB804 1-414-813-11 FERRITE, EMI (SMD) (2012)
FB805 1-414-813-11 FERRITE, EMI (SMD) (2012)
FB806 1-216-295-91 SHORT CHIP 0
< IC >
IC401 6-707-315-01 IC RT8H055C-T1
< JACK >
J301 1-818-840-21 JACK (i / LINE OUT(OPTICAL))
J402 1-818-841-11 JACK, DC
< COIL >
L101 1-400-849-21 INDUCTOR, CHIP 100uH (2518)
L201 1-400-849-21 INDUCTOR, CHIP 100uH (2518)
< LINE FILTER >
LF401 1-416-405-21 FILTER, CHIP EMI (COMMON MODE)
< TRANSISTOR >
Q301 6-550-364-01 TRANSISTOR 2SD2652T106
Q302 6-550-364-01 TRANSISTOR 2SD2652T106
Q303 6-550-375-01 TRANSISTOR UMD2N-TR
JACKEGH
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
