33
D-NE20/NE20LS
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Q304 8-729-047-48 TRANSISTOR UMD12N-TR
Q305 6-551-132-01 TRANSISTOR EMG6 (EXCEPT AEP, EE, UK)
Q306 6-550-527-01 TRANSISTOR NTHD5904T1
Q307 6-551-186-01 TRANSISTOR EMX18
Q401 8-729-602-36 TRANSISTOR 2SA1602TP-1EF
Q402 6-550-760-01 TRANSISTOR 2SA1363-T111-1E
Q403 6-550-364-01 TRANSISTOR 2SD2652T106
< RESISTOR >
R102 1-218-945-11 RES-CHIP 220 5% 1/16W
R103 1-218-981-11 RES-CHIP 220K 5% 1/16W
R202 1-218-945-11 RES-CHIP 220 5% 1/16W
R203 1-218-981-11 RES-CHIP 220K 5% 1/16W
R303 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R304 1-220-803-81 RES-CHIP 4.7 5% 1/16W
R305 1-218-981-11 RES-CHIP 220K 5% 1/16W
R306 1-218-981-11 RES-CHIP 220K 5% 1/16W
R307 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R308 1-218-953-11 RES-CHIP 1K 5% 1/16W
R309 1-218-989-11 RES-CHIP 1M 5% 1/16W
R310 1-218-953-11 RES-CHIP 1K 5% 1/16W
R311 1-218-969-11 RES-CHIP 22K 5% 1/16W
R312 1-218-989-11 RES-CHIP 1M 5% 1/16W
R313 1-218-969-11 RES-CHIP 22K 5% 1/16W
R314 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R315 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R316 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(EXCEPT AEP, EE, UK)
R401 1-218-989-11 RES-CHIP 1M 5% 1/16W
R402 1-218-985-11 RES-CHIP 470K 5% 1/16W
R403 1-218-985-11 RES-CHIP 470K 5% 1/16W
R404 1-208-943-11 METAL CHIP 220K 0.5% 1/16W
R405 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R406 1-218-941-81 RES-CHIP 100 5% 1/16W
R407 1-245-927-21 METAL CHIP 0.22 1% 1/5W
R408 1-218-973-11 RES-CHIP 47K 5% 1/16W
R409 1-218-945-11 RES-CHIP 220 5% 1/16W
R410 1-218-973-11 RES-CHIP 47K 5% 1/16W
R411 1-218-989-11 RES-CHIP 1M 5% 1/16W
R501 1-218-965-11 RES-CHIP 10K 5% 1/16W
R502 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R503 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R504 1-218-969-11 RES-CHIP 22K 5% 1/16W
R505 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R506 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R507 1-218-965-11 RES-CHIP 10K 5% 1/16W
R508 1-218-969-11 RES-CHIP 22K 5% 1/16W
R509 1-218-953-11 RES-CHIP 1K 5% 1/16W
R510 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R511 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R512 1-218-969-11 RES-CHIP 22K 5% 1/16W
R513 1-218-945-11 RES-CHIP 220 5% 1/16W
R514 1-218-953-11 RES-CHIP 1K 5% 1/16W
R901 1-216-864-11 SHORT CHIP 0
< COMPOSITION CIRCUIT BLOCK >
RB301 1-233-787-11 RES, NETWORK 1.0K (1608)
< SWITCH >
S501 1-762-805-41 SWITCH, PUSH (1 KEY)
S502 1-572-922-11 SWITCH, SLIDE (HOLD .)
S503 1-771-105-11 SWITCH, TACTILE (–( ))
S504 1-771-105-11 SWITCH, TACTILE (+( ))
S505 1-771-105-11 SWITCH, TACTILE (–(VOL))
S506 1-771-105-11 SWITCH, TACTILE (.)
S507 1-771-105-11 SWITCH, TACTILE (+(VOL))
S508 1-771-105-11 SWITCH, TACTILE (>)
S509 1-771-105-11 SWITCH, TACTILE (x)
S510 1-771-105-11 SWITCH, TACTILE (u)
< THERMISTOR >
TH401 1-805-719-11 THERMISTOR, POSITIVE
< VARISTOR >
VDR901 1-801-862-11 VARISTOR, CHIP (1608)
*************************************************************
JACK SUB BOARD
***************
< JACK >
J401 1-818-841-11 JACK, DC
*************************************************************
SUB BOARD
**********
2-187-574-01 TERMINAL (+), BATTERY
*************************************************************
MISCELLANEOUS
**************
0102 X-3383-995-1 OPTICAL PICK-UP ASSY (DAX-25EV)
M901 A-3174-848-A MOTOR ASSY, TURN TABLE (SPINDLE)
M902 A-3174-850-A MOTOR ASSY, SLED (SLED)
ACCESSORIES
************
0 1-478-845-21 ADAPTOR, AC (AC-ES3010K2) (CH)
0 1-478-846-21 ADAPTOR, AC (AC-ES3010K2) (US, CND)
0 1-478-847-21 ADAPTOR, AC (AC-ES3010K2) (KR)
0 1-478-848-21 ADAPTOR, AC (AC-ES3010K2) (AEP, EE, E18)
0 1-478-849-21 ADAPTOR, AC (AC-ES3010K2) (UK, EA, HK)
0 1-478-850-21 ADAPTOR, AC (AC-ES3010K2) (AUS)
0 1-478-853-22 ADAPTOR, AC (AC-ES3010K2) (JE)
0 1-569-007-22 ADAPTOR, CONVERSION 2P (JE)
1-756-120-51 BATTERY, NICKEL HYDROGEN (EXCEPT US)
1-756-120-61 BATTERY, NICKEL HYDROGEN (US, CND)
1-816-149-32 PLUG, DC
2-187-958-01 COVER, BATTERY CASE
2-318-320-11 MANUAL, INSTRUCTION (ENGLISH)
(EXCEPT EA, KR)
2-318-320-21 MANUAL, INSTRUCTION
(SPANISH, PORTUGUESE, FRENCH) (CND, AEP)
2-318-320-31 MANUAL, INSTRUCTION
(DUTCH, GERMAN, ITALISH) (AEP)
JACK JACK SUB SUB
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
