Sony D-NE240 - MAIN Board, CD Mechanism (CDM-3525 A); Cabinet (Inner) Assy, SWITCH Board

D-NE240/NE241/NE241CK
6
3-3. MAIN BOARD, CD MECHANISM (CDM-3525A)
3-4. CABINET (INNER) ASSY, SWITCH BOARD
3 insulator
3 insulator
3 insulator
4 CD mechanism
(CDM-3525A)
1 Remove four solders.
orange
red
gray
black
2 flexible board
(CN501)
5 MAIN board
7 eight screws
1 two bosses
4 two bosses
2 spring (L)
3 spring (R)
5 battery case lid
6 cabinet (inner) assy
8 cover (upper lid)
9 SWITCH board
0 upper lid
