D-NE300/NE300CK/NE301/NE301CK/NE306CK
5
SECTION 3
DISASSEMBLY
Note: Follow the disassembly procedure in the numerical order given.
3-2. CABINET (LOWER) SECTION
• This set can be disassembled in the order shown below.
3-1. DISASSEMBLY FLOW
4
five screws
5
claw
5
two claws
2
two screws
7
flexible flat (20core) cable
(CN801)
1
Open the cabinet (upper) section.
8
cabinet (lower) section
3
Open the battery case lid.
5
two claws
6
3-2. CABINET (LOWER) SECTION
(Page 5)
3-3. OPTICAL PICK-UP ASSY (CDM-3325ER)
(Page 6)
3-5. LIQUID CRYSTAL DISPLAY PANEL (LCD2001),
SWITCH BOARD
(Page 7)
SET
3-4. MAIN BOARD
(Page 6)
