D-NE300/NE300CK/NE301/NE301CK/NE306CK
6
3-3. OPTICAL PICK-UP ASSY (CDM-3325ER)
3-4. MAIN BOARD
4
OP flexible board
(CN601)
6
optical pick-up assy
(CDM-3325ER)
5
insulator
5
insulator
5
insulator
3
2
two connectors
(CN401, CN402
1
knob spacer
2
MAIN board
1
Note : On installation of main board,
adjust the position of switch
(S810) and knob (hold).
knob (hold)
S810
