D-NE300/NE300CK/NE301/NE301CK/NE306CK
7
3-5. LIQUID CRYSTAL DISPLAY PANEL (LCD2001), SWITCH BOARD
2
eight screws
1
Open the cabinet (upper) section.
3
claw
7
sheet
9
cover
8
SWITCH board
6
liquid crystal display panel (LCD2001)
(CN2001)
5
flexible flat (20core) cable
(CN2002)
4
Open the cover.
3
claw
3
