Sony D-V8000 - Page 31

– 31 –
Pin No. Pin Name I/O Function
92 DOE B O
Output enable signal output to the D-RAM (IC903) “L” active
93 AIN I
Audio interface serial data input terminal Not used (open)
94 RBCK I
Audio interface bit clock signal (2.8224 MHz) input terminal Not used (open)
95 ARFS I
Audio interface L/R sampling clock signal (44.1 kHz) input terminal Not used (open)
96 TDMCLK I
Bit clock signal (2.8224 MHz) input from the CXD2545Q (IC601)
97
TDMDR I
Serial data input from the CXD2545Q (IC601)
98
TDMFS I
L/R sampling clock signal (44.1 kHz) input from the CXD2545Q (IC601)
99 DCAS B O
Column address strobe signal output to the D-RAM (IC903) “L” active
100 VSS —
Ground terminal
