– 55 –
#§ Q881 D
2 V/DIV, 2 µs/DIV
#∞ Q881 G
2 V/DIV, 2 µs/DIV
#¡ IC861 7 (OUT2)
2 V/DIV, 2 µs/DIV
#™ IC861 0 (OUT2)
2 V/DIV, 2 µs/DIV
#£ Q891 G
2 V/DIV, 2 µs/DIV
#¢ T891 4
5 V/DIV, 2 µs/DIV
#º IC861 1 (CT)
200 mV/DIV, 2 µs/DIV
680 mVp-p
4.9
µ s
4.6 µ s
5.5 Vp-p
5.5 Vp-p
4.5 µ s
5.6 Vp-p
5.2
µ s
12.8 Vp-p
5.2 µ s
5.4 Vp-p
4.5
µ s
5.8 Vp-p
4.5 µ s
