SECTION 7
EXPLODED VIEWS
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
• The mechanical parts with no reference num-
ber in the exploded views are not supplied.
• Hardware (# mark) list and accessories and
packing materials are given in the last of the
electrical parts list.
NOTE:
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Color Indication of Appearance Parts
Example:
KNOB, BALANCE (WHITE) . . . (RED)
↑↑
Parts Color Cabinet's Color
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
(1) CABINET SECTION-1
4
5
3
2
1
6
6
not
supplied
not
supplied
not
supplied
1 4-996-341-01 BUTTON, CONTROL
2 X-4949-052-1 CABINET (UPPER) ASSY
3 4-982-475-01 WINDOW, RAY CATCHER
4 A-3320-060-A LID BLOCK ASSY, UPPER
5 4-996-352-01 SHAFT
6 3-336-395-01 SCREW (B2X10), TAPPING
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
To Next Page
