SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Ref. No. Part No. Description Remark
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
A-3321-005-A LCD BOARD, COMPLETE
********************
1-776-149-11 FLEXIBLE CABLE, FLAT (FCR-1)
4-996-337-01 BASE, BUTTON
4-996-338-01 HOLDER, LCD
< CAPACITOR >
C401 1-115-156-11 CERAMIC CHIP 1uF 10V
C402 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C403 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C404 1-115-416-11 CERAMIC CHIP 1000PF 5% 25V
< CONNECTOR >
CN401 1-573-370-21 CONNECTOR, FFC/FPC 30P
< IC >
IC401 8-749-014-29 IC RS-350
< RESISTOR >
R401 1-216-813-11 METAL CHIP 220 5% 1/16W
R402 1-216-158-00 RES, CHIP 22 (3216)
R403 1-216-813-11 METAL CHIP 220 5% 1/16W
R421 1-218-692-11 METAL CHIP 1K 0.5% 1/16W
R422 1-218-696-11 METAL CHIP 1.5K 0.5% 1/16W
R423 1-218-700-11 METAL CHIP 2.2K 0.5% 1/16W
R424 1-218-704-11 METAL CHIP 3.3K 0.5% 1/16W
R425 1-218-708-11 METAL CHIP 4.7K 0.5% 1/16W
R441 1-218-692-11 METAL CHIP 1K 0.5% 1/16W
R442 1-218-696-11 METAL CHIP 1.5K 0.5% 1/16W
R443 1-218-700-11 METAL CHIP 2.2K 0.5% 1/16W
R444 1-218-704-11 METAL CHIP 3.3K 0.5% 1/16W
R445 1-218-708-11 METAL CHIP 4.7K 0.5% 1/16W
< SWITCH >
S401 1-771-273-21 SWITCH, PUSH (OPEN)
S421 1-762-366-21 SWITCH, TACTILE (π POWER OFF)
S422 1-762-366-21 SWITCH, TACTILE (® SELECT)
S423 1-762-366-21 SWITCH, TACTILE (MEGA BASS)
S424 1-762-366-21 SWITCH, TACTILE (ESP)
S425 1-762-366-21 SWITCH, TACTILE (PLAY MODE)
S426 1-762-366-21 SWITCH, TACTILE (REPEAT/ENTER)
S441 1-762-366-21 SWITCH, TACTILE (ˆ RETURN)
S442 1-762-366-21 SWITCH, TACTILE (– MENU)
S443 1-762-366-21 SWITCH, TACTILE (≠ PREV)
S444 1-762-366-21 SWITCH, TACTILE (fl)
S445 1-762-366-21 SWITCH, TACTILE (± NEXT)
S446 1-762-366-21 SWITCH, TACTILE (+ MENU)
************************************************************
A-3293-778-A MAIN BOARD, COMPLETE
*********************
< CAPACITOR >
C101 1-107-686-11 TANTAL. CHIP 4.7uF 20% 16V
C102 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C103 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C104 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C105 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C106 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C107 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C201 1-107-686-11 TANTAL. CHIP 4.7uF 20% 16V
C202 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C203 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C204 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C205 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C206 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C207 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C301 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C321 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C322 1-126-209-11 ELECT CHIP 100uF 20% 4V
C323 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C324 1-126-246-11 ELECT CHIP 220uF 20% 4V
C325 1-162-922-11 CERAMIC CHIP 39PF 5% 50V
C326 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C327 1-162-922-11 CERAMIC CHIP 39PF 5% 50V
C328 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C329 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C330 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C332 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C360 1-104-915-11 TANTAL. CHIP 2.2uF 20% 20V
C361 1-115-156-11 CERAMIC CHIP 1uF 10V
C362 1-126-602-11 ELECT CHIP 3.3uF 20% 50V
C363 1-115-156-11 CERAMIC CHIP 1uF 10V
LCD MAIN
When indicating parts by reference
number, please include the board.
To Next Page
