14
GB
A SPEAKERS jacks (page 29)
B HDMI OUT jack (page 30)
C TV (DIGITAL IN OPTICAL) jack (DAV-
DZ510/DAV-DZ610/DAV-DZ810 only)
(page 30)
D EZW-T100 slot (DAV-DZ810 only)
(page 60)
E ANTENNA (COAXIAL 75Ω FM) jack
(page 33)
F TV (AUDIO IN R/L) jacks (page 30)
G VIDEO OUT jack (page 30)
H COMPONENT VIDEO OUT jacks
(page 30)
* CAUTION
(DAV-DZ810 only)
Please do not remove the screws unless you are
installing the EZW-T100.
Rear panel
CENTER
SUR R
SUBWOOFER
FRONT L
SUR L
FRONT R
SPEAKERS
SPEAKERS
COAXIAL 75
FM
ANTENNA
DIGITAL
IN
OPTICAL
TV
OUT
ARC
AUDIO IN
P
B
/C
B
P
R
/C
R
Y
LR
VIDEO
OUT
TV
COMPONENT VIDEO OUT
EZW-T100
Screws*
To Next Page
