Sony DCR-HC44E - Page 35

DCR-HC44E/HC46/HC46E_L2
4-28
FP-031, FP-032, FP-228
MIC902
4 PIN
CONNECTOR
Q902
PT4850FJE00F
TAPE TOP
SENSOR
S903
(MODE SWITCH)
FP-032
FLEXIBLE
BOARD
FP-228
FLEXIBLE
BOARD
DEW
SENSOR
D901
GL453SE0000F
(TAPE LED)
S902
(REC PROOF)
FP-031 FLEXIBLE BOARD
M902
LOADING MOTOR
G
Vcc
-
+
G-
Vcc +
H902
HW-105A-CDE-T
T REEL SENSOR
H901
HW-105A-CDE-T
S REEL SENSOR
05
Q901
PT4850FJE00F
TAPE END SENSOR
LM_LOAD LM_LOAD
LM_UNLOAD LM_UNLOAD
DEW-
DEW+
XMODE_SW_A XMODE_SW_B XMODE_SW_C
SW_COM
XREC_PROOF
CHIME_VDD
CHIME_SDA
CHIME_SCK
MIC/REC_SW_GND
TAPE_TOP
XCCDOWN_SW
Cin_GND
TREEL-
TREEL+
HALL_VCC
SREEL+
SREEL-
HALL_GND
TAPE_LED_K TAPE_LED_A
TOP/END_GND
TAPE_END
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27
NC
28 29
1
A
D
F
B
E
538
C
62 974
S901
(CC DOWN)
DEW-
DEW+
1
2
MODE_SW_A
MODE_SW_A
1
2
MODE_SW_A
SW_COM/SW_GND
3
4
DEW-
DEW+
1
2
MODE_SW_A
MODE_SW_A
1
2
MODE_SW_A
SW_COM/SW_GND
3
4
M
PAGE 4-19
VC-418
(14/18)
CN1007
of LEVEL3
