Sony DCR-HC44E - Mounted Parts Location

4-41
DCR-HC44E/HC46/HC46E_L2
4-4. MOUNTED PARTS LOCATION
no mark : side A
*
mark : side B
4-3. PRINTED WIRING BOARDS
4-3. PRINTED WIRING BOARDS
* C202 B-2
* C203 B-1
* C205 A-1
* C208 A-1
* C213 A-1
* C214 A-1
* CN202 B-1
* FB201 A-1
IC201 A-1
* L201 A-1
* Q201 A-2
* Q202 A-1
* R206 A-1
* R209 A-1
* R210 A-1
* R211 A-1
CD-633 BOARD
CD-633
