Sony DCR-HC44E - Page 45

DCR-HC44E/HC46/HC46E_L2
4-40
FP-031, FP-032, FP-228
FP-031 (1 layer), FP-032 (1 layer), FP-228 (1 layer)
: Uses unleaded solder.
DEW
SENSOR
M902
LOADING MOTOR
S903
MODE SWITCH
M
(Dilect Solder)
(Dilect Solder)
1
14
2
1-677-049-
11
1-867-810-
11
1-867-811-
11
12
29
1
FP-228 FLEXIBLE BOARD
FP-032 FLEXIBLE BOARD
FP-031 FLEXIBLE BOARD
S902
(REC PROOF)
S901
(CC DOWN)
D901
(TAPE LED)
H902
T REEL SENSOR
H901
S REEL SENSOR
MIC902
Q902
TAPE TOP SENSOR
4 PIN
CONNECTOR
Q901
TAPE END SENSOR
GND
VCC
-
+
GND
VCC
-
+
05
