Sony DCR-HC44E - Page 48

4-44E
DCR-HC44E/HC46/HC46E_L2
no mark : side A
*
mark : side B
4-3. PRINTED WIRING BOARDS
4-3. PRINTED WIRING BOARDS
PD-283, SI-053
PD-283 BOARD
C9602 C-4
C9603 C-4
C9604 B-2
C9605 C-3
C9606 C-2
CN9601 A-2
CN9602 C-4
CN9603 B-2
CN9604 C-4
CN9605 C-2
D9602 C-3
* D9603 B-6
* D9604 C-6
* D9605 A-6
Q9601 C-3
Q9602 C-4
Q9603 C-2
R9602 C-4
R9603 C-4
R9604 C-4
R9605 C-4
R9607 C-2
R9609 C-3
* BT601 B-2
C602 D-1
* C604 E-1
C608 E-2
C610 E-1
* C611 E-2
* C612 D-2
* C613 D-1
* C614 E-2
* C615 E-2
* C616 D-1
* C617 D-1
CN601 C-1
* CN602 D-2
* CN606 D-2
* D602 D-1
* D603 D-1
D606 B-2
FB601 D-1
FB602 D-1
* IC601 C-2
* IC602 D-2
* L601 E-2
* R616 D-2
* R617 D-2
* R618 D-1
* R619 D-1
* R623 B-2
* R624 B-1
* RB601 E-2
SE601 E-2
* SE602 E-2
SI-053 BOARD
