DCR-SR58E/SR68/SR68E/SR78E/SR88/SR88E_L2
2-9E
Ref. No. Part No. Description Ref. No. Part No. Description
Ref. No. Part No. Description
2-2. ELECTRICAL PARTS LIST
A-1750-996-A CD-786 BOARD, COMPLETE
**********************
(IC7101 (CCD IMAGER) is not included in CD-786 complete board.)
< CAPACITOR >
C7101 1-127-820-11 CERAMIC CHIP 4.7uF 10% 16V
C7103 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C7104 1-127-820-11 CERAMIC CHIP 4.7uF 10% 16V
C7105 1-164-854-11 CERAMIC CHIP 15PF 5% 50V
C7108 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
CN7101 1-816-648-61 FFC/FPC CONNECTOR (LIF) 20P
< IC >
IC7101 8-753-331-34 ICX690NKF-H (SR68/SR88) (Note 2)
IC7101 8-753-331-35 ICX691NKF-H
(SR58E/SR68E/SR78E/SR88E) (Note 2)
(IC7101 (CCD IMAGER) is not included in CD-786.)
< COIL >
* L7101 1-481-425-21 INDUCTOR 10uH
< TRANSISTOR >
Q7101 8-729-923-27 TRANSISTOR 2SC4082-T106P
< RESISTOR >
R7101 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
1-880-150-11 FP-1168 FLEXIBLE BOARD
*********************
^
1-880-503-11 FP-1216 FLEXIBLE BOARD
*********************
^
1-880-504-11 FP-1217 FLEXIBLE BOARD
*********************
^
1-881-061-11 FP-1239 FLEXIBLE BOARD
*********************
^
A-1750-997-A MS-432 BOARD, COMPLETE
**********************
(BT7301 is not included in MS-432 complete board.)
< BATTERY HOLDER >
BH7301 1-756-615-61 HOLDER, BATTERY (Note 1)
< BATTERY >
BT7301 1-756-134-12 BATTERY, STORAGE, LITHIUM (Note 1)
< CONNECTOR >
CN7301 1-819-572-51 FFC/CONNECTOR, FPC (LIF (NON-ZIF)) 30P
CN7302 1-822-837-21 CARD CONNECTOR
< DIODE >
D7301 6-501-216-01 DIODE CL-271HR-C-TS
< FERRITE BEAD >
FB7301 1-469-580-21 FERRITE 0uH
FB7302 1-469-580-21 FERRITE 0uH
FB7303 1-469-580-21 FERRITE 0uH
FB7304 1-469-580-21 FERRITE 0uH
FB7305 1-469-580-21 FERRITE 0uH
FB7306 1-469-580-21 FERRITE 0uH
FB7307 1-469-580-21 FERRITE 0uH
FB7308 1-469-580-21 FERRITE 0uH
FB7311 1-469-580-21 FERRITE 0uH
< RESISTOR >
R7307 1-220-169-11 METAL CHIP 75 5% 1/16W
R7308 1-220-169-11 METAL CHIP 75 5% 1/16W
R7309 1-220-169-11 METAL CHIP 75 5% 1/16W
R7315 1-218-941-81 METAL CHIP 100 5% 1/16W
R7316 1-218-941-81 METAL CHIP 100 5% 1/16W
R7317 1-218-941-81 METAL CHIP 100 5% 1/16W
R7318 1-218-941-81 METAL CHIP 100 5% 1/16W
R7319 1-218-941-81 METAL CHIP 100 5% 1/16W
R7320 1-220-169-11 METAL CHIP 75 5% 1/16W
R7328 1-218-942-11 METAL CHIP 120 5% 1/16W
< TERMINAL >
* TB7301 1-780-431-11 ON-BOARD CONTACT
^
A-1750-998-A OC-024 BOARD, COMPLETE
**********************
< CAPACITOR >
* C8602 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
* CN8601 1-816-654-61 FFC/FPC CONNECTOR (LIF) 6P
CN8602 1-816-654-61 FFC/FPC CONNECTOR (LIF) 6P
< RESISTOR >
R8601 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R8602 1-218-955-11 METAL CHIP 1.5K 5% 1/16W
R8603 1-218-954-11 METAL CHIP 1.2K 5% 1/16W
< SWITCH >
S8601 1-786-914-31 SWITCH, TACTILE
< SENSOR >
* SE8602 1-487-118-11 GMR SENSOR
^
CD-786 FP-1168 FP-1216 MS-432FP-1217 OC-024FP-1239
A-1751-597-A PD-404 BOARD, COMPLETE
**********************
(SE6401 is not supplied, but it is included in PD-404 complete board .)
< CAPACITOR >
C6401 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C6402 1-100-581-81 CERAMIC CHIP 0.0047uF 10% 50V
* C6403 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C6404 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
* C6405 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C6406 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6408 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6409 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C6410 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C6411 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C6412 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C6414 1-100-591-91 CERAMIC CHIP 1uF 10% 25V
C6415 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
* C6416 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
* C6417 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
< CONNECTOR >
* CN6401 1-822-378-11 CONNECTOR, FPC (ZIF) 33P
* CN6402 1-821-503-11 CONNECTOR, FPC (ZIF) 39P
CN6403 1-816-654-61 FFC/FPC CONNECTOR (LIF) 6P
< COIL >
* L6401 1-481-102-21 INDUCTOR 10uH
* L6402 1-481-102-21 INDUCTOR 10uH
< TRANSISTOR >
* Q6401 6-552-337-01 TRANSISTOR DMG9640N0L
* Q6402 6-552-337-01 TRANSISTOR DMG9640N0L
< RESISTOR >
R6402 1-218-953-11 METAL CHIP 1K 5% 1/16W
R6403 1-218-953-11 METAL CHIP 1K 5% 1/16W
R6405 1-218-985-11 METAL CHIP 470K 5% 1/16W
< SENSOR >
SE6401 (Not supplied) AMR SENSOR
(SE6401 is supplied included in PD-404 complete board.)
^
PD-404
Caution
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Dispose of used batteries according to the instructions.
Please refer to LEVEL 3 about the ELECTRICAL PARTS LIST of
DA-049 and VC-587.
Note 1:
Replace the battery holder (BH7301) together when
replacing the lithium storage battery (BT7301) on the MS-
432 board. (The battery holder removed once cannot be
used again.)
When mounting these parts, mount new battery holder first
and attach new lithium battery next.
Note 2: Be sure to read “Precautions for Replacement of Imager”
on page 6-1 when changing the imager.
To Next Page
