DCR-SR58E/SR68/SR68E/SR78E/SR88/SR88E_L2
– 2 –
SPECIFICATIONS
– ENGLISH –
SPECIFICATIONS
These specifications are extracted from instruction manual of
DCR-SR58E/SR68E/SR78E/SR88E.
– ENGLISH –
System
Signal format: PAL color, CCIR standards
Movie recording format:
Video: MPEG-2 PS
Audio recording system:
Dolby Digital 2ch
Dolby Digital Stereo Creator
Photo file format
: DCF Ver.2.0 Compatible
: Exif Ver.2.21 Compatible
: MPF Baseline Compatible
Recording media (Movie/Photo)
Internal hard disk
DCR-SR58E/SR68E: 80 GB
DCR-SR78E/SR88E: 120 GB
“Memory Stick PRO Duo” media
SD memory card, SDHC memory card (Class
2, 4, 6, 10)
When measuring media capacity, 1 GB equals
1 billion bytes, a portion of which is used for
system management and/or application files.
The capacity that a user can use is below.
DCR-SR58E/SR68E: Approx. 79.3 GB
DCR-SR78E/SR88E: Approx. 119 GB
Image device
2.25 mm (1/8 type) CCD (Charge Coupled
Device)
Gross: Approx. 800 000 pixels
Effective (Movie, 16:9): Approx.
490 000 pixels
Effective (Photo, 16:9): Approx. 310 000
pixels
Effective (Photo, 4:3): Approx. 410 000 pixels
Lens
Carl Zeiss Vario-Tessar
60 × (Optical), 2 000 × (Digital)
DCR-SR58E/SR68E/SR78E/SR88E
Filter diameter: 30 mm (1 3/16 in.)
F1.8 to 6.0
Focal length:
f=1.8 to 108 mm (3/32 to 4 3/8 in.)
When converted to a 35 mm still camera
For movies: 39 to 2 340 mm (1 9/16 to
92 1/4 in.) (16:9)
For photos: 44 to 2 640 mm (1 3/4 to 104 in.)
(4:3)
Color temperature: [AUTO], [ONE PUSH],
[INDOOR] (3 200 K), [OUTDOOR]
(5 800 K)
Minimum illumination
3 lx (lux) ([AUTO SLW SHUTTR] is set to
[ON],
shutter speed 1/25 second)
Input/Output connectors
A/V Remote Connector: Video/audio output
jack
USB jack: mini-AB
(DCR-SR58E/SR78E: output only)
LCD screen
Picture: 6.7 cm (2.7 type, aspect ratio 16:9)
Total number of pixels: 230 400 (960 × 240)
General
Power requirements: DC 6.8 V/7.2 V (battery
pack) DC 8.4 V (AC Adaptor)
Average power consumption: During camera
recording, using LCD screen at normal
brightness: 2.0 W
Operating temperature: 0 °C to 40 °C
(32 °F to 104 °F)
Storage temperature: –20 °C to + 60 °C
(–4 °F to +140 °F)
Dimensions (approx.)
56 × 65 × 107 mm (2 1/4 × 2 5/8 × 4 1/4 in.)
(w/h/d) including the projecting parts
56 × 65 × 115 mm (2 1/4 × 2 5/8 × 4 5/8 in.)
(w/h/d) including the projecting parts,
and the supplied rechargeable battery pack
attached
Mass (approx.)
280 g (9 oz) main unit only
320 g (11 oz) including the supplied
rechargeable battery pack
AC Adaptor AC-L200C/AC-L200D
Power requirements: AC 100 V - 240 V,
50 Hz/60 Hz
Current consumption: 0.35 A - 0.18 A
Power consumption: 18 W
Output voltage: DC 8.4 V*
Operating temperature: 0 °C to 40 °C
(32 °F to 104 °F)
Storage temperature: –20 °C to + 60 °C
(–4 °F to +140 °F)
Dimensions (approx.): 48 × 29 × 81 mm
(1 15/16 × 1 3/16 × 3 1/4 in.) (w/h/d) excluding
the projecting parts
Mass (approx.): 170 g (6.0 oz) excluding the
power cord (mains lead)
* See the label on the AC Adaptor for other
specifications.
Rechargeable battery pack NP-FV30
Maximum output voltage: DC 8.4 V
Output voltage: DC 7.2 V
Maximum charge voltage: DC 8.4 V
Maximum charge current: 2.12 A
Capacity
typical: 3.6 Wh (500 mAh)
minimum: 3.6 Wh (500 mAh)
Type: Li-ion
Design and specifications of your camcorder and
accessories are subject to change without notice.
• Manufactured under license from Dolby
Laboratories.
System
Signal format: NTSC color, EIA standards
Movie recording format:
Video: MPEG-2 PS
Audio recording system:
Dolby Digital 2ch
Dolby Digital Stereo Creator
Photo file format
: DCF Ver.2.0 Compatible
: Exif Ver.2.21 Compatible
: MPF Baseline Compatible
Recording media (Movie/Photo)
Internal hard disk
DCR-SR68: 80 GB
DCR-SR88: 120 GB
“Memory Stick PRO Duo” media
SD memory card, SDHC memory card (Class
2, 4, 6, 10)
When measuring media capacity, 1 GB equals
1 billion bytes, a portion of which is used for
system management and/or application files.
The capacity that a user can use is below.
DCR-SR68: Approx. 79.3 GB
DCR-SR88: Approx. 119 GB
Image device
2.25 mm (1/8 type) CCD (Charge Coupled
Device)
Gross: Approx. 680 000 pixels
Effective (Movie, 16:9): Approx. 410 000
pixels
Effective (Photo, 16:9): Approx. 250 000
pixels
Effective (Photo, 4:3): Approx. 340 000 pixels
Lens
Carl Zeiss Vario-Tessar
60 × (Optical), 2 000 × (Digital)
Filter diameter: 30 mm (1 3/16 in.)
F1.8 to 6.0
Focal length:
f=1.8 to 108 mm (3/32 to 4 3/8 in.)
When converted to a 35 mm still camera
For movies: 39 to 2 340 mm (1 9/16 to
92 1/4 in.) (16:9)
For photos: 44 to 2 640 mm (1 3/4 to 104
in.) (4:3)
Color temperature: [AUTO], [ONE PUSH],
[INDOOR] (3 200 K), [OUTDOOR]
(5 800 K)
Minimum illumination
3 lx (lux) ([AUTO SLW SHUTTR] is set to
[ON],
shutter speed 1/30 second)
Input/Output connectors
A/V Remote Connector: Video/audio output
jack
USB jack: mini-AB
LCD screen
Picture: 6.7 cm (2.7 type, aspect ratio 16:9)
Total number of pixels: 230 400 (960 × 240)
General
Power requirements: DC 6.8 V/7.2 V (battery
pack) DC 8.4 V (AC Adaptor)
Average power consumption: During camera
recording, using LCD screen at normal
brightness: 2.0 W
Operating temperature: 0 °C to 40 °C
(32 °F to 104 °F)
Storage temperature: –20 °C to + 60 °C
(–4 °F to +140 °F)
Dimensions (approx.)
56 × 65 × 107 mm (2 1/4 × 2 5/8 × 4 1/4 in.)
(w/h/d) including the projecting parts
56 × 65 × 115 mm (2 1/4 × 2 5/8 × 4 5/8 in.)
(w/h/d) including the projecting parts,
and the supplied rechargeable battery pack
attached
Mass (approx.)
280 g (9 oz) main unit only
320 g (11 oz) including the supplied
rechargeable battery pack
AC Adaptor AC-L200C/AC-L200D
Power requirements: AC 100 V - 240 V,
50 Hz/60 Hz
Current consumption: 0.35 A - 0.18 A
Power consumption: 18 W
Output voltage: DC 8.4 V*
Operating temperature: 0 °C to 40 °C
(32 °F to 104 °F)
Storage temperature: –20 °C to + 60 °C
( –4 °F to +140 °F)
Dimensions (approx.): 48 × 29 × 81 mm (1 15/16
× 1 3/16 × 3 1/4 in.) (w/h/d) excluding the
projecting parts
Mass (approx.): 170 g (6.0 oz) excluding the
power cord (mains lead)
* See the label on the AC Adaptor for other
specifications.
Rechargeable battery pack NP-FV30
Maximum output voltage: DC 8.4 V
Output voltage: DC 7.2 V
Maximum charge voltage: DC 8.4 V
Maximum charge current: 2.12 A
Capacity
typical: 3.6 Wh (500 mAh)
minimum: 3.6 Wh (500 mAh)
Type: Li-ion
Design and specifications of your camcorder and
accessories are subject to change without notice.
• Manufactured under license from Dolby
Laboratories.
These specifications are extracted from instruction manual of
DCR-SR68/SR88.
