2-4
DCR-TRV345E/TRV350/TRV351/TRV355E/TRV356E
2-2. PD-181 BOARD
1 Four screws (M1.7)
5 Two screws
(M1.7)
8 P cabinet (M) assembly
7 Flexible board
(CN5702)
6 Connector
(CN5701)
2 Claw
4 P cabinet (C)
Bottom View
3 Claw
qs Claw
qa Screw (M1.7)
9 Flexible board
(CN5601)
0 Flexible board
(CN5501)
qd PD-181 board
