Sony DCR-TRV345E - Mounted Parts Location

4-92E
COVER
COVER
DCR-TRV345E/TRV350/TRV351/TRV355E/TRV356E
4-5. MOUNTED PARTS LOCATION
no mark : side A
* mark : side B
4-3. PRINTED WIRING BOARDS
4-3. PRINTED WIRING BOARDS
PD-181, SI-036
PD-181 BOARD
C5501 C-2
C5504 C-4
C5505 C-3
C5506 C-3
C5507 C-3
C5509 C-2
C5510 C-3
C5511 C-4
C5512 C-4
C5515 C-4
C5516 B-4
C5517 B-3
C5518 B-3
C5519 B-3
C5527 C-3
C5532 C-3
C5533 A-4
C5534 A-5
C5536 B-5
C5540 B-5
C5603 A-3
C5604 C-5
C5605 C-5
C5606 A-1
C5607 A-4
CN5501 A-5
CN5502 B-2
CN5601 A-1
CN5701 B-1
CN5702 D-1
D5502 B-4
D5503 A-5
D5601 C-5
IC5501 C-3
IC5502 C-4
IC5601 D-5
IC5602 C-5
L5501 C-2
L5505 B-4
L5601 A-4
L5602 A-3
Q5503 B-5
Q5504 B-5
Q5505 B-5
Q5506 B-5
Q5508 B-5
Q5601 C-5
Q5604 A-3
R5501 C-3
R5503 C-3
R5505 C-3
R5506 C-4
R5507 C-4
R5508 C-4
R5509 C-4
R5510 C-4
R5511 C-4
R5512 C-4
R5522 B-3
R5542 C-2
R5551 C-5
R5572 B-5
R5573 B-5
R5574 B-5
R5575 B-5
R5576 B-5
R5577 B-5
R5578 B-5
R5579 B-5
R5588 A-4
R5590 C-4
R5592 B-5
R5602 C-5
R5603 C-5
R5606 C-5
R5607 C-5
R5610 A-3
RB5501 B-3
RB5502 A-5
RB5601 C-5
T5601 A-3
SI-036 BOARD
C751 B-1
* C752 C-1
C755 C-2
* C757 B-2
* C758 B-2
CN751 A-1
CN753 C-1
CN754 C-2
D752 C-2
D753 C-2
* D754 C-1
D756 B-3
* FB753 B-1
IC751 C-2
L751 D-2
Q751 B-3
Q752 C-2
* Q753 C-2
* R754 C-2
* R755 C-2
R756 C-3
R757 B-3
R760 C-2
* R761 C-1
R762 D-2
* SE751 B-1
* SE752 B-2
* VDR751 B-2
* VDR752 B-2
VDR753 B-1
