Sony DCR-TRV360 - Mounted Parts Location

4-71E
DCR-TRV360/TRV361/TRV460/TRV460E/TRV461E
no mark : side A
* mark : side B
4-3. PRINTED WIRING BOARDS
4-3. PRINTED WIRING BOARDS
4-4. MOUNTED PARTS LOCATION
PD-205, SI-041
PD-205 BOARD
C6001 A-2
C6002 B-2
C6003 A-3
C6004 A-2
C6005 A-2
C6006 B-3
C6007 A-4
C6009 B-2
C6010 B-2
C6011 A-5
C6012 C-4
C6013 C-4
C6014 C-3
C6015 C-2
C6017 C-2
C6018 C-2
C6019 A-3
C6020 B-3
C6028 C-4
C6029 C-2
CN6001 B-1
CN6003 D-4
CN6004 D-2
CN6005 C-1
CN6007 D-3
D6001 C-2
D6004 C-4
IC6001 B-2
IC6002 C-2
L6001 A-3
L6002 A-4
L6003 A-4
Q6003 A-4
Q6004 C-2
Q6005 C-2
Q6006 C-3
Q6008 C-3
Q6009 C-3
R6005 B-4
R6009 B-2
R6010 C-4
R6012 B-2
R6013 B-2
R6014 C-4
R6019 C-2
R6021 C-3
R6022 C-2
R6023 C-2
R6030 B-2
RB6001 C-4
T6001 B-4
SI-041 BOARD
C758 B-4
C759 C-3
* CN751 B-1
* CN752 C-1
* CN753 D-4
* CN754 C-4
D751 C-2
D752 C-2
* D753 B-2
* D754 B-2
* D755 D-3
D756 C-2
D759 C-2
FB751 C-4
* IC751 C-2
* J751 D-2
* J752 A-1
Q751 A-2
R752 B-2
R753 B-2
* R756 C-3
* R757 D-3
R763 B-2
* R764 C-3
* R765 D-3
SE751 B-3
* SE752 B-3
