Quick reference
MODE button (28)
FINDER 2D/3D (display) button (27)
Power zoom lever (26)
PHOTO button (30)
START/STOP button (28)
A/V Remote Connector
HDMI OUT jack
(USB) jack (35)
Memory card access lamp (25)
While the lamp is lit or flashing, this product
is reading or writing data.
Memory card slot (25)
RESET button
Press RESET using a pointed object.
Press RESET to initialize all the settings
including the clock setting.
Camera recording lamp
The camera recording lamp lights up in red
during recording. The lamp flashes when the
remaining memory card capacity or battery
power is low.
IPD ADJ dial (21)
Diopter adjustment dial (21)
Viewfinder
(Movie)/ (Photo) lamps (28)
MIC (PLUG IN POWER) jack
(headphones) jack
DC IN jack (17)
MANUAL dial (30)
MANUAL button (30)
Strap mount (16)
Tripod receptacle
Attach a tripod (sold separately) to the
tripod receptacle using a tripod screw (sold
separately: the length of the screw must be less
than 5.5 mm (7/32 in.)).
Battery cover (17)
Battery cover lock (17)
