2-13
DSC-N1_L2
2. DISASSEMBLY
2. DISASSEMBLY
5 Insert the flexible cable (beware of loose insertion).
Flexible board
Z reset sensor
6 Install the Z reset sensor (press fitting into zoom gear block).
