Sony DSC-W100 - Mounted Parts Location

4-26E
DSC-W100_L2
no mark : side A
*
mark : side B
4-3. PRINTED WIRING BOARDS
4-3. PRINTED WIRING BOARDS
SW-479
SW-479 BOARD
* C001 C-1
* C002 C-2
C003 C-1
C004 C-1
* C005 C-1
C006 C-1
* C007 C-2
* C008 C-2
* C010 C-2
C011 C-1
C012 C-2
* C020 B-1
* CN001 B-1
CN002 C-2
CN003 B-2
CN004 A-1
D001 C-1
D002 C-1
* L001 C-1
* R001 C-2
* R003 C-2
R004 C-1
* R005 B-2
R006 B-1
R007 B-2
* R010 C-1
R011 C-1
* R050 C-1
* R051 C-2
* R052 C-1
* R053 B-2
* R054 B-2
* R055 B-2
* S050 C-1
* S051 A-2
* S052 B-1
* S053 C-2
* S054 B-1
* S055 A-2
* S056 B-2
* S057 B-1
4-4. MOUNTED PARTS LOCATION
