A ON/OFF (Power) button
B Shutter button
C Flash
D Self-timer lamp/Smile Shutter
lamp/AF illuminator
E Lens
F Charge lamp
G Microphone
H LCD screen
I For shooting: W/T (zoom)
button
For viewing: (Index) button/
(Playback zoom) button
J Mode switch
(Still Image)/ (Sweep
Panorama)/ (Movie)
K Hook for wrist strap
L Control button
MENU on: v/V/b/B
MENU off: DISP (Display
Setting)/ (Self-Timer)/
(Smile Shutter)/ (Flash)
M / (In-Camera Guide/Delete)
button
N (Playback) button
O MENU button
P Battery insertion slot
Q Battery eject lever
R Access lamp
S Memory card slot
T Tripod socket hole
• Use a tripod with a screw less
than 5.5 mm (7/32 inches) long.
Otherwise, you cannot firmly
secure the camera, and damage to
the camera may occur.
U Speaker
V Battery/Memory card cover
W USB / A/V OUT terminal
