Appendix (ECM-77B)
[Applicable S/No. ]
Choice the parts according to below serial number.
Old : #902000 or before
New : #902001 and after
[Parts change info. And Applicable S/No. ]
< Change point >
- SLEEVE ASSY (Length and part number)
- TRANSFORMER MOUNTED PWB (Mounted parts and part number)
- No function and performance has changed.
Old (#902000 or before)
New (#902001 and after)
Part name
Part number
Part name
Part number
1
CAPSURE ASSY
A4510050A
←
←
2
CASE ASSY, AMPLIFER
X25374135
←
←
3
SLEEVE, BATTERY
444822102 *1
SLEEVE ASSY
A1908370C *1
SLEEVE ASSY
A4531042C *1
4
BUSHING, POWER
253741402 *2
458506801 *2
←
←
5
PCB, EX-1251
A1900797A *3
←
←
6
SPRING
252207201
←
←
7
LID, CASE
252207001
←
←
8
TERMINAL, BATTERY
252207111
←
←
9
CASE, BATTERY
252208401
←
←
10
LUG 2
762350501
←
←
11
LW 2, TYPE (A)
762330507
←
←
12
SCREW +P 2X3
762125512
←
←
13
MOUNTED PWB,
TRANSFORMER
A4538027A ← A4538027B
14
SCREW, PRECISION +K 2X3
762745217
←
←
15
SLEEVE, PIN, CANON
252206803 *1
SLEEVE ASSY
A1908370C *1
SLEEVE ASSY
A4531042C *1
16
SCREW, PRECISION +P 2X7
762755387
←
←
17,18
CANNON XLR3-14 PIN INSERT
150909611
←
←
MANUAL, INSTRUCTION
259925301
←
377670204
MANUAL, INSTRUCTION
259925311
←
377670215
MANUAL, INSTRUCTION
259925321
←
377670224
MANUAL, INSTRUCTION
377670231
*1 #3 “SLEEVE, BATTERY” and #15 “SLEEVE, PIN, CANON” are supplied as assembled.
Please order “SLEEVE ASSY A4531042C”.
*2 Difference of two choices of #4 “BUSHING, POWER”, see the APM17-046R.
*3 Difference of #5 “PCB, EX-1251” and old EX board, see the APM12-037.
