Command List
EVI-D70/P Inquiry Command List (2/2)
Inquiry Command Command Packet Inquiry Packet Comments
CAM_LR_ReverseModeInq 8x 09 04 61 FF y0 50 02 FF On
y0 50 03 FF Off
CAM_FreezeModeInq 8x 09 04 62 FF y0 50 02 FF On
y0 50 03 FF Off
CAM_PictureEffectModeInq 8x 09 04 63 FF y0 50 00 FF Off
y0 50 02 FF Neg.Art
y0 50 04 FF B&W
CAM_ICRModeInq 8x 09 04 01 FF y0 50 02 FF On
y0 50 03 FF Off
CAM_AutoICRModeInq 8x 09 04 51 FF y0 50 02 FF On
y0 50 03 FF Off
CAM_MemoryInq 8x 09 04 3F FF y0 50 pp FF pp: Last Recall Memory No.
CAM_DisplayModeInq 8x 09 04 15 FF y0 50 02 FF On
(8x 09 06 06 FF) y0 50 03 FF Off
CAM_TitleDisplayModeInq 8x 09 04 74 FF y0 50 02 FF On
y0 50 03 FF Off
CAM_MuteModeInq 8x 09 04 75 FF y0 50 02 FF On
y0 50 03 FF Off
CAM_KeyLockInq 8x 09 04 17 FF y0 50 00 FF Off
y0 50 02 FF On
CAM_IDInq 8x 09 04 22 FF y0 50 0p 0q 0r 0s FF pqrs: Camera ID
CAM_VersionInq 8x 09 00 02 FF y0 50 00 01 mnpq: Model Code (04xx)
mn pq rs tu vw FF rstu: ROM version
vw: Socket Number (=02)
See page 34.
CAM_AlarmInq 8x 09 04 6B FF y0 50 02 FF On
y0 50 03 FF Off
CAM_AlarmModeInq 8x 09 04 6C FF y0 50 pp FF pp: Alarm Mode
CAM_AlarmDayNightLevelInq 8x 09 04 6D FF y0 50 0p 0p 0p ppp: Day setting AE Level
0q 0q 0q 0r 0r 0r FF qqq: Night setting AE Level
rrr: Now AE Level
CAM_PictureFlipModeInq 8x 09 04 66 FF y0 50 02 FF On
y0 50 03 FF Off
CAM_AlarmDetectLevelInq 8x 09 04 6E FF y0 50 01 FF Detect Level “High”
y0 50 00 FF Detect Level “Low”
Pan-tiltModeInq 8x 09 06 10 FF y0 50 pq rs FF pqrs: Pan/Tilter Status See page 51.
Pan-tiltMaxSpeedInq 8x 09 06 11 FF y0 50 ww zz FF ww = Pan Max Speed
zz = Tilt Max Speed
Pan-tiltPosInq 8x 09 06 12 FF y0 50 0w 0w 0w 0w wwww = Pan Position
0z 0z 0z 0z FF zzzz = Tilt Position See page 51.
IR_ReceiveReturn y0 07 7D 01 04 00 FF Power ON/OFF
y0 07 7D 01 04 07 FF Zoom tele/wide
y0 07 7D 01 04 38 FF AF On/Off
y0 07 7D 01 04 33 FF CAM_Backlight
y0 07 7D 01 04 3F FF CAM_Memory
y0 07 7D 01 06 01 FF Pan_tiltDrive
