Command List
EVI-D80N/D80P/D90N/D90P Inquiry Command List (2/2)
Inquiry Command Command Packet Inquiry Packet Comments
CAM_WDParameterInq
1)
8x 09 04 2D FF y0 50 0p 0q 0r 0s 0t 0u 00 00 FF p: Screen display
q: Detection sensitivity
r: Blocked-up shadow correction level
s: Blown-out highlight correction level
tu: Exposure ratio of short exposure
CAM_ApertureInq 8x 09 04 42 FF y0 50 00 00 0p 0q FF pq: Aperture Gain
CAM_HRModeInq 8x 09 04 52 FF y0 50 02 FF On
y0 50 03 FF
Off
CAM_NRInq 8x 09 04 53 FF y0 50 0p FF p: NR level
CAM_PictureEffectModeInq 8x 09 04 63 FF y0 50 00 FF Off
y0 50 02 FF
Neg.Art
y0 50 04 FF
B&W
CAM_ICRModeInq
1)
8x 09 04 01 FF y0 50 02 FF On
y0 50 03 FF
Off
CAM_AutoICRModeInq
1)
8x 09 04 51 FF y0 50 02 FF On
y0 50 03 FF
Off
CAM_AutoICRThresholdInq
1)
8x 09 04 21 FF y0 50 00 00 0p 0q FF pq: ICR ON → OFF Threshold Level
CAM_IDInq 8x 09 04 22 FF y0 50 0p 0q 0r 0s FF pqrs: Camera ID
CAM_VersionInq 8x 09 00 02 FF y0 50 00 01
mn pq rs tu vw FF
mnpq: Model Code (D80:050C/D90:050D)
rstu: ROM version
vw: Socket Number (=02)
See page 23.
Information Display 8x 09 7E 01 18 FF y0 50 02 FF
On
y0 50 03 FF
Off
IR_Receive 8x 09 06 08 FF y0 50 02 FF On
y0 50 03 FF
Off
IR_ReceiveReturn y0 07 7D 01 04 00 FF Power ON/OFF
y0 07 7D 01 04 07 FF Zoom tele/wide
y0 07 7D 01 04 38 FF AF On/Off
y0 07 7D 01 04 33 FF
CAM_Backlight
y0 07 7D 01 04 3F FF
CAM_Memory
y0 07 7D 01 06 01 FF
Pan_tiltDrive
IR_ConditionInq 8x 09 06 34 FF y0 50 00 FF Stable reception from the IR Remote Commander
y0 50 01 FF Unstable reception from the IR Remote Commander
y0 50 02 FF Impossible to detect the infrared signals from
the Remote Commander because the camera is
turned on by the Remote Commander.
Pan-tiltMaxSpeedInq 8x 09 06 11 FF y0 50 ww zz FF ww = Pan Max Speed
xx = Tilt Max Speed
Pan-tiltPosInq
2)
8x 09 06 12 FF y0 50 0w 0w 0w 0w
0z 0z 0z 0z FF
wwww = Pan Position
zzzz = Tilt Position Speed
See page 42.
Pan-tiltModeInq 8x 09 06 10 FF y0 50 pq rs FF pqrs: Pan-tilt Status
See page 42.
1) The command is available on EVI-D90N/P only.
2) If a Pan-tiltPosInq command is received after Pan-tiltDrive Reset, the pan/tilt position may be different for 1-2 addresses.
