Sony EVI-D80 - Pan;Tilt Status Code List; Pan;Tilt Position (for reference); LED Status

42
Command List
Pan/Tilt Status Code List
P Q R S
- - - - - - - - 0 - - - - - - 1 A Pan movement all the way to the left
- - - - - - - - 0 - - - - - 1 - A Pan movement all the way to the right
- - - - - - - - 0 - - - - 1 - - A Tilt movement all the way up
- - - - - - - - 0 - - - 1 - - - A Tilt movement all the way down
- - - - - - - - - - 0 0 - - - - Pan movement is correct
- - - - - - - - - - 0 1 - - - - Pan position cannot be detected
- - - - - - 0 0 0 - - - - - - - The Tilt movement is correct
- - - - - - 0 1 0 - - - - - - - The Tilt position cannot be detected
- - - - 0 0 - - 0 - - - - - - - No movement instructions
- - - - 0 1 - - 0 - - - - - - - In the midst of a Pan/Tilt
- - - - 1 0 - - 0 - - - - - - - Pan/Tilt completed
- - - - 1 1 - - 0 - - - - - - - Pan/Tilt failed
- - 0 0 - - - - 0 - - - - - - - Not initialized
- - 0 1 - - - - 0 - - - - - - -
Initializing
- -1 0 - - - - 0 - - - - - - - Initialization completed
- -1 1 - - - - 0 - - - - - - - Initialization failed
( - : optional)
Pan/Tilt Position (for reference)
Parameter (position)
PAN E1E5 (-170 degree) to 1E1B (+170 degree)
TILT FC75 (-20 degree) to 0FF0 (+90 degree) (IMAGE FLIP: OFF)
F010 (-90 degree) to 038B (+20 degree) (IMAGE FLIP: ON)
LED Status
Status POWER (Green) STANDBY (Orange)
Main power ON Power On (including initializing period) On Off
When receiving infrared signals form Remote Commander
Blinking Off
At position detection error
On Blinking
Standby status
Power off by VISCA or the Remote Commander
Off On
Main power Off Off Off
Initialization
error
Pan/tilt error Blinking Blinking
Internal error(LSI, etc.) Blinking alternately
BOTTOM
switch
Setting error
(Example: when the BOTTOM switch 5 is set to ON.)
On On
